Sonance SB46-55 Quick Start Manual

SONANCE SOUNDBAR
Q U I C K S TA R T G U I D E - B R A C K E T W A L L M O U N T
Sonance Soundbar Models: SB46-55 | SB46-65 | SB46-75 | SB46-85
Adjustable Width Soundbar Models: SB46 L | SB46 M

Box Contents

(2) Flat Soundbar connectors
(2) Recessed Soundbar connectors
Hardware Pack
A. (4) M8 10mm screws for
display attachment rails
B. (4) M8 14mm screws for
flat Soundbar connector
C. (4) M8 23mm short screws for
recessed Soundbar connector
D. (4) M8 38mm long screws for
recessed Soundbar connector
E. (4) M6 25mm screws
F. (4) M8 25mm screws
G. (8) M8 nuts
H. (8) M6 washers
I. (8) M8 washers
J. (4) Rubber feet
Flat Connector Recessed Connector
For Mounting Option 2: Table Top or Mounting Option 3: Key Hole Wall Mount (not attached to display) and slim
display application, see detailed installation manual at: www.sonance.com/home-theater/soundbar/soundbar
(2) Display attachment rails
(1) Key hole wall mount template
(2) Display spacers
A. x 4
D. x 4
G. x 8
Mounting
Option 1:
Bracket
Wall Mount
(1) Soundbar
B. x 4
H. x 8
Mounting
Option 2:
Table Top
(1) Quickstart Guide
(2) Key hole
wall mounts
(2) Black opaque strips
(Included with adjustable
width soundbars only)
E. x 4
I. x 8
Mounting
Option 3:
Key Hole
Wall Mount
C. x 4
F. x 4
J. x 4
P . 1
