INTRODUCTION
Thank you for purchasing Sonance Symphony
When properly installed your new speakers will give you years of entertainment
pleasure. This manual covers these speaker models: Symphony S625
S624
, Symphony S623
, Symphony S622
T
T

SAFETY WARNING:

These speakers have FastMount
tabs that prevent the speaker from falling out
®
of the mounting hole during the installation process.
The edges of the FastMount tabs are very sharp.
Use caution when handling the speaker.

BOX CONTENTS

Your Sonance Symphony speaker box should contain the following items:
(2) Symphony speakers, (2) Plastic paint plugs (installed on fronts of speakers);
(2) Paintable grilles; (1) Mounting cutout template (in packaging)

SPEAKER PLACEMENT

Home Theater Speaker Placement
Left, Center & Right Channels
• Place the left & right speakers on either side of the video screen, anywhere from
6 feet to 10 feet apart and 38 – 42 inches from the floor.
• If possible, locate the left and right speakers at least 18 inches away from the
side walls.
• If possible, locate the center speaker at the same height as the left & right
channel speakers (38 – 42 inches from the floor).
• If you must place the center speaker above or below a video screen, place it
no more than 2 feet above or below the center of the left and right speakers.
This will maintain consistent tonality between all 3 front channel speakers.
• The main listening position should be between 8 and 12 feet away from the
speakers.
Use Figure 1 as a guide.
18"
From Side
Wall
2'
(max.)
L
, C
& R
H
E F T
E N T E R
I G H T
T-series in-wall speakers.
®
T
, Symphony S621
.
T
T
6' – 10'
18"
Apart
From Side
Wall
F
1 :
I G U R E
T
S
P
O M E
H E A T E R
P E A K E R
L A C E M E N T
I N S T R U C T I O N M A N U A L
S O N A N C E S Y M P H O N Y
I N - W A L L
Surround Speakers
(5.1-Channel System)
Locate the surround channel
speakers on the side walls
, Symphony
approximately 2 – 6 feet
behind the listening position,
at least 5 feet from the floor.
Use Figure 2 as a guide.
Surround Speakers
(7.1-Channel System)
• Left & Right Surround
Place the left
Speakers:
and right surround speakers
directly to the sides of the
listening position, at least 5
feet from the floor.
• Surround Back Speakers:
wall, between 3 feet and 6 feet apart and at least 5 feet from the floor.
Use Figure 3 as a guide.
Right
Front
Speaker
Video
Screen
Center
Speaker
Left
Front
Speaker
F
3 : S
I G U R E
Stereo (2-Channel) Placement
• Place the left and right speakers anywhere from 6 feet to 10 feet apart, with
the main listening position as close to midway between the speakers as possible.
• The speakers should be at least 2 feet away from the side walls.
• The main listening position should be between 4 and 10 feet away from the
speakers.
• In most cases pivoting the tweeter of each speaker directly towards the main
listening position will help maximize the stereo soundstage.
Use the left and right speaker placement in Figure 1 as a guide.
S P E A K E R S
2' – 6'
F
I G U R E
S
S
U R R O U N D
P E A K E R
Place the surround back speakers in the rear
Right Surround
Speaker
Left Surround
Speaker
P
7 . 1 - C
P E A K E R
L A C E M E N T I N A
T
®
5' – 7'
2 :
P
L A C E M E N T
Right
Surround Back
Speaker
Left
Surround Back
Speaker
S
H A N N E L
Y S T E M
1
