Equipment maintenance

-------------------------------------------------------------------------------------------------------------------------------------------

1.Maintenance and cleaning of guide rail

This product USES the stainless steel guide rail, used in the normal environment
(25 degrees temperature, 30~60% humidity) will not get rusty. In order to
ensure the better performance of the guide rail, it is necessary to coat XYZ three
linear guide rail with lubricating oil regularly(usually 1 month) .
After using the CNC function, there maybe swarf on the guide rail, please
cleaned up with a brush immediately, otherwise with rail movement,the swarf is
very easy to damage the guide rail.

2. Maintenance of printing platform

This product USES the heating film + metal platform+soft magnet plate + sticker
(order from bottom to top), combine to printing platform, sticker is one of the
consumables, after using long time, there will be deformation, damage, not
sticky, etc.it needs to be replaced according to the condition , in order to ensure
better print effect. The replacement only needs to be removed from the soft
magnet plate and affixed again.
In daily use, the distance between the FDM nozzle and the printing platform
should be reasonably set to prevent the nozzle from burning the stickers
directly or even the soft magnet plate. After printing, if there are still residual
materials on the sticker, the sticker surface should be cleaned up and tidy by
scraping with a blade.
When taking the model, try to remove the model after cooling the platform
before bending the soft magnetic plate. Every time bending the soft magnetic
plate should be bent in the same direction, do not repeatedly bending in different
directions, this will lead to the soft magnetic plate broken.

3.CNC plate

CNC Carving Raft is made of PVC expansion sheet. It is used to pad between
the metal platform and the workpiece during CNC carving to prevent the CNC
Toolhead from hitting the metal platform and causing damage to the metal
platform or CNC Toolhead itself. CNC Carving Raft is a consumable and usually
it does not need to be replaced for proper use.
4.Laser Toolhead life
Laser Toolhead are consumable. In normal environment (temperature -20 to
40 degrees, humidity 20% to 80%) the service life is 8000 hours. The laser has
a wavelength of 405nm, 1500mw power, and a working voltage is 5V. Do not
touch the laser when it is working. Keep it in a dry and dust-free sealed bag or
box after daily use.
5.CNC Toolhead life
CNC Toolhead is consumables. In normal environment (temperature -20 to
40 degrees, humidity 20% to 80%) the service life is 10000 hours. CNC motor
USES carbon brush dc motor, the maximum power is about 40W, DO NOT
touch when CNC toolhead working, or observing CNC work ,make sure you
ware safety glasses. The toolhead is connected to the CNC tool through a
coupling.When replacing the tool, be sure to tighten the meter screw on the
coupling to prevent the tool from falling.
---------------------------------------------------------------------------------------------------------------------------------------
