LASER Engraving

--------------------------------------------------------------------------------------------------------------------------------------------

1.Install Laser Toolhead

(1)Power up, if there are filament rest
in the Toolhead, please enter the option
Filament>Unload Filament at first to exit the
consumables, otherwise it will be easy to
plug in.
(2) Confirm the current Toolhead type on
the screen. If it shows the Laser Toolhead,
jump straight to step 4. If it shows other
Toolhead, proceed to step 3.
(3) (3) Use Menu Button, enter Utility >
Change ToolHeader > Change To Laser Toolhead,
browse the contents displayed on the
screen and click To the last step.
(4) Loose the hand screw fixing the current
Toolhead, remove the original Toolhead
upward but keep the cable connected.
Remove it and put it aside. Pay attention
not to unplug the cable at this moment.
------------------------------------------------------------------------------------------------------------------------------------------
