Revision 0.1
7700 MultiFrame Manual
7780TG-ASI ASI Test Signal Generator
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for evertz 7700
Summary of Contents for evertz 7700
-
Page 1: Table Of Contents
Figures Figure 1-1: 7780TG-ASI Block Diagram ....................1 Figure 2-1: 7780TG-ASI Rear Panel....................2 Figure 2-2: 7700 Chassis........................3 Figure 2-3: Compact Flash Card Installed ................... 3 Figure 2-4: COM Port Properties Window ................... 4 Figure 2-5: HyperTerminal Main Menu ....................5 Figure 2-6: Network Configuration Sub-Menu .................. - Page 2 Nov 08 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either expressed or implied.
-
Page 3: Overview
7700 MultiFrame Manual 7780TG-ASI ASI Test Signal Generator OVERVIEW The 7780TG-ASI Test Signal Generator provides a cost-effective method of generating ASI test signals. The 7780TG-ASI is ideal for checking signal path integrity, or to determine system performance over varying cable lengths, or for providing slates for emergency broadcasting. The 7780TG-ASI generates custom test signals in DVB-ASI transport stream formats. -
Page 4: Installation
7700 MultiFrame Manual 7780TG-ASI ASI Test Signal Generator INSTALLATION The 7780TG-ASI module comes with a companion rear plate that has 4 BNC connectors and 2xIP RJ45 connectors. For information on mounting the rear plate and inserting the module into the frame see the 7700FR chapter section 3. -
Page 5: Figure 2-2: 7700 Chassis
7700 MultiFrame Manual 7780TG-ASI ASI Test Signal Generator Figure 2-2: 7700 Chassis Before inserting the card, make sure the Compact Flash is properly inserted in the front of the 7780TG- ASI as shown in Figure 2-3. Figure 2-3: Compact Flash Card Installed 7780TG-ASI-3 Revision 0.1... -
Page 6: Figure 2-4: Com Port Properties Window
7700 MultiFrame Manual 7780TG-ASI ASI Test Signal Generator Before inserting the front card, connect the serial cable to the board using the rainbow coloured serial cable provided. Now insert the 7780TG-ASI card into the corresponding front slots ensuring the card lines up with the slot runners on the bottom and the top of the chassis. -
Page 7: Configuring The Basic Network Settings
In normal operation it should not be necessary to use either of these options. (6) Engineering/Debug This menu is for Evertz personnel only. You may be requested to access and execute options within this menu when seeking technical support from Evertz. Guidance will be given should this be required. -
Page 8: Figure 2-6: Network Configuration Sub-Menu
7700 MultiFrame Manual 7780TG-ASI ASI Test Signal Generator Select option (1) Set IP Address and configure the IP address for the 7780TG-ASI ensuring that the IP address is not already in use on the network. Now select option (2) Set Netmask from the Network Configuration menu and configure the correct subnet mask for your network. -
Page 9: Connecting To Vlpro
VLPro communicates with the card and confirms its configuration. Please consult your network administrator if you continue to have problems connecting the card with VLPro. Alternatively, contact Evertz Microsystems Ltd. or your authorized reseller for technical support. 7780TG-ASI-7 Revision 0.1... -
Page 10: Card Configuration
7700 MultiFrame Manual 7780TG-ASI ASI Test Signal Generator CARD CONFIGURATION 3.1. FILES MANAGEMENT Right-click the IP address of the 7780TG-ASI in the VLPRO Tree. Select View Configuration. The right window will display the 7780TG-ASI File management menus as shown in Figure 3-1. - Page 11 7700 MultiFrame Manual 7780TG-ASI ASI Test Signal Generator • Import: icon shows an arrow pointing to the compact flash. It is used for importing a file to the Compact Flash from the local PC where VLPRO client is running. When clicking on this icon, locate the file to import and click the “import”...
-
Page 12: Playout Configuration
7700 MultiFrame Manual 7780TG-ASI ASI Test Signal Generator 3.2. PLAYOUT CONFIGURATION Right-click the ASI Output 1 under the IP address of the 7780TG-ASI in the VLPRO Tree. Select View Configuration. The right window will display the 7780TG-ASI Configuration and Bitrate View tab menus as shown in Figure 3-2. - Page 13 7700 MultiFrame Manual 7780TG-ASI ASI Test Signal Generator o Pause: The orange double-line icon is used to pause the playback. Clicking on this icon will stop the playout of the file loaded into the RAM. Selecting the Pause button again will resume the playout of the file, continuing from the point at which the playout was paused.
- Page 14 7700 MultiFrame Manual 7780TG-ASI ASI Test Signal Generator o File Standard: The user can choose between MPEG-2, DVB, and ATSC standard. This field only affects what context is used to interpret the transport stream. This is only used to display the proper table under the Bitrate view and does not affect the playout.
-
Page 15: Compact Flash Maintenance
7700 MultiFrame Manual 7780TG-ASI ASI Test Signal Generator COMPACT FLASH MAINTENANCE The 7780TG-ASI comes with an 8G Compact Flash. It has MPEG-2 TS files built in. If you want to replace the flash or add your own flash, make sure it is at least an Ultra II Compact Flash (for speed). -
Page 16: Specifications
Wide Band Jitter: < 0.2 UI 5.2. ELECTRICAL Voltage: + 12V DC Power: 45 Watts EMI/RFI: Complies with FCC Part 15, class A and EU EMC directive 5.3. PHYSICAL 7700 or 7800 frame mounting: Number of slots: 7780TG-ASI-14 Revision 0.1... -
Page 17: Card Edge Controls
7700 MultiFrame Manual 7780TG-ASI ASI Test Signal Generator CARD EDGE CONTROLS The 7780TG-ASI card edge simply provides information about the version number at this time. For control and monitoring please use VistaLINK ® 7780TG-ASI-15 Revision 0.1... - Page 18 7700 MultiFrame Manual 7780TG-ASI ASI Test Signal Generator This page left intentionally blank 7780TG-ASI-16 Revision 0.1...
