ResMed Confidential Proprietary Information, not to be reproduced or made available to third parties
without prior consent from ResMed and not to be used in any unauthorised way.
 ResMed Ltd 2018.
SPECIFICATION
– PRINTED MATERIALS
Rev
Change
Note
1
K001608-00
1.
ORACLE DESCRIPTION
AirCurve10 ST-A UG AMER MULTI
2.
TRANSLATION DESCRIPTION
Refer to the Change History on the English source listed for summary of changes in each version.
Rev
English source
1
288009r4 plus changes shown
below
3.
PRINT DETAILS
Print according to master spec R370-7240
4.
RESMED QC INSPECTION
For general sampling and inspection requirements, refer to AWI203-002 Appendix A, Printed or Unprinted
Materials and Labels, Criteria 1, 2, 3, 4, 5, 6, 8 and 9
Additional requirement
a) None
5.
FOR ALL OTHER REQUIREMENTS, REFER TO RESMED SUPPLIER MANUAL AQP119.
6.
CHANGE HISTORY
Section
Update
Tech
Update of Wireless approval certificate id to add information for 4G
Specs
FCC ID: 2ACHL-AIR104G
IC ID: 9103A-AIR104G
Tech
Update of Classification to be IEC 60601-1:2005+A1:2012
Specs
Tech
Update of Wireless information to match Machine data for Tech comms rev
Specs
65
Cleaning
Add warning 'Regularly clean the tubing assembly, water tub and mask for
optimal therapy and to prevent the growth of germs that can adversely the
patient's health.
Date
Document prepared by
document
drafted
24 July 2018
Melanie Theaker
AirCurve 10 ST-A User Guide AMER Multi
(Name)
Lisa Oliver or delegate refer to change note.
This translation replaces...
288131
DOC NO
PAGE
REV
Document Checked by
(Name)
288156
1 of 130
1

Advertisement

Table of Contents
loading

Related Manuals for ResMed AirCurve 10 ST-A

Summary of Contents for ResMed AirCurve 10 ST-A

  • Page 1 ResMed Confidential Proprietary Information, not to be reproduced or made available to third parties DOC NO 288156 without prior consent from ResMed and not to be used in any unauthorised way.  ResMed Ltd 2018. PAGE 1 of 130 SPECIFICATION –...
  • Page 3 User guide English | Français | Español | Português 288156 covers.indd 2 24/07/2018 12:09:57 PM...
  • Page 4 288156 covers.indd 3 24/07/2018 12:09:57 PM...

  • Page 5: Indications For Use

    Indications for use AirCurve 10 ST-A The AirCurve 10 ST-A is indicated to provide non-invasive ventilation for patients weighing more than 30 lb (13 kg) with respiratory insufficiency or obstructive sleep apnea (OSA). The iVAPS mode is indicated for patients weighing more than 66 lb (30 kg).
  • Page 6 At a glance The AirCurve 10 includes the following: • Device with HumidAir ™ integrated humidifier • Water tub • Air tubing • Power supply unit Travel bag • SD card (already inserted). • Contact your care provider for a range of accessories available for use with the device including: •...

  • Page 7: About Your Device

    About your device Air outlet HumidAir humidifier (water tub) Air filter cover Screen Retention clip Adapter cover Power inlet SD card cover Serial number and device number 10 LED alarm indicator About the control panel Press to start/stop therapy. Start/Stop button Press and hold for three seconds to enter power save mode.
  • Page 8 6. Connect the free end of the air tubing firmly onto the assembled mask. See the mask user guide for detailed information. Recommended masks are available on www.resmed.com. Note: Ensure the device is placed so that the LED alarm indicator is clearly visible.

  • Page 9: Starting Therapy

    Starting therapy 1. Fit your mask. 2. Press Start/Stop or breathe normally if SmartStart ™ is enabled. You will know that therapy is on when the Monitoring screen is displayed. The pressure bar shows the inspiratory and expiratory pressures in green. The green bar will expand and contract as you breathe in and out.

  • Page 10: Power Save Mode

    Power save mode Your AirCurve 10 device records your therapy data. In order to allow it to transmit the data to your care provider, you should not unplug the device. However, you can put it into power save mode to save electricity.

  • Page 11: Humidity Level

    Ramp Down Ramp Down is intended to make stopping therapy more comfortable by reducing your pressure over a fixed 15 minute period. This option will only be available to you via your care provider. To enable Ramp Down: 1. In My Options, turn the dial to highlight Ramp Down and then press the dial.

  • Page 12: More Options

    Mask Fit Mask Fit is designed to help you assess and identify possible air leaks around your mask. To check Mask Fit: 1. Fit the mask as described in the mask user guide. 2. In My Options, turn the dial to highlight Run Mask Fit and then press the dial.

  • Page 13: Multiple Alarms

    Muting activated alarms To mute the alarm: 1. Press the dial. A list of activated alarms will appear and the flashing alarm mute icon will be displayed in the top right corner of the screen. The alarm will be muted for 2 minutes. 2.
  • Page 14 Disassembling 1. Hold the water tub at the top and bottom, press it gently and pull it away from the device. 2. Open the water tub and discard any remaining water. 3. Hold the cuff of the air tubing and gently pull it away from the device. Grip the retention clip and pull up to release the power cord.

  • Page 15: Therapy Data

    To replace the air filter: 1. Open the air filter cover and remove the old air filter. The air filter is not washable or reusable. 2. Place a new air filter onto the air filter cover and then close it. Make sure the air filter is fitted at all times to prevent water and dust from entering the device.

  • Page 16: Traveling By Plane

    You can use your AirCurve 10 device on a plane as it meets the Federal Aviation Administration (FAA) requirements. Air travel compliance letters can be downloaded and printed from www.resmed.com. When using the device on a plane: •...

  • Page 17: General Troubleshooting

    Troubleshooting If you have any problems, have a look at the following troubleshooting topics. If you are not able to fix the problem, contact your care provider or ResMed. Do not try to open the device. General troubleshooting Problem/possible cause...
  • Page 18 Problem/possible cause Solution Air pressure in my mask seems too low (it feels like I am not getting enough air) Wait for air pressure to build up or turn Ramp Time off. Ramp may be in progress Press Start/Stop to stop therapy then press Start/Stop to Ramp Down may be in progress restart and continue therapy.

  • Page 19: Alarms Troubleshooting

    Problem/possible cause Solution Device may be in Airplane Mode. Turn off Airplane Mode, see Traveling by plane. Data transfer is not enabled for your device. Talk to your care provider about your settings. My screen and buttons are flashing but there is no alarm sound or message Software upgrade is in progress.
  • Page 20 Note: the retention clip should be in the open position when inserting the plug. For instructions refer to the Setup section. If the problem continues, contact your local ResMed dealer or ResMed office. Do not open the device. All other error messages, for example, System fault, refer to user guide, Error 0XX An unrecoverable error has occurred on the device.
