DIMENSION AND PARTS

Pressure tank
Terminal cover
Display LED
Power cord
Discharge

SETTING THE OPERATING MODE

Control button
Operating mode
Display indicator
Green LED
Red LED
Green/Red LED(+ Suction Pressure)
Green/Red LED flashing simultaneously
Green/Red LED flashing by turns
PE-410MA
How to control the button
(when push the button, below 1-2-3-4 repeating)
1. Push the button one time : Auto mode 1 → Auto mode 2
2. Push the button two times : Auto mode 2 → Manual mode 1
3. Push the button Three times : Manual mode 1 → Manual mode 2
4. Push the button four times : Manual mode 2 → Auto mode1
Drain screw
Auto Mode 1
Auto Mode 2
Auto Mode 3
Manual Mode1
Manual Mode2
PE-350EA
How to control the button
(when push the button, below 1-2-3-4-5 repeating)
1. Push the button one time : Auto mode 1 → Auto mode 2
2. Push the button two times : Auto mode 2 → Auto mode 3
3. Push the button three times : Auto mode 3 → Manual mode 1
4. Push the button four times : Manual mode 1 → Manual mode 2
5. Push the button five times : Manual mode 2 → Auto mode1
10
Hopper cap
Casing
Flange
Suction
Mode
PE-410MA
1.0~2.3kgf/㎠
Pressure
1.5~2.3kgf/㎠
Range
Constant high speed driving
Constant medium speed driving
151
195
162
207
232
Red LED
Green LED
Condition
PE-350EA
1.0~1.6kgf/㎠
1.5~1.6kgf/㎠
- 1.5~1.6kgf/㎠
