Switch 4200 Family - Rear View Detail; Power Socket; Console Port - 3Com SuperStack 3 Getting Started Manual

16 C 1: I
HAPTER NTRODUCING THE
Switch 4200 Family
— Rear View Detail

Power Socket

Power Socket

Console Port

S S 3 S
UPER TACK WITCH
LED Color
Power/Self Test LED
Green
Green flashing The Switch is either downloading software or is initializing
Yellow
Off
Alert LED
Green flashing The Switch Alert LED has been configured via the CLI or Web
Off
Figure 4 Switch 4200 Family — rear view
The Switch automatically adjusts its power setting to any supply voltage
in the range 100-240 VAC.
The console port allows you to connect a terminal and perform remote or
local out-of-band management. The console port uses a standard null
modem cable and is set to auto-baud, 8 data bits, no parity and 1 stop
bit.
The Switch 4226T, Switch 4250T and Switch 4228G have a Redundant
Power Supply (RPS) connector on the rear panel. Refer to the
documentation supplied with these models for details.
4200 F
AMILY
Indicates
The Switch is powered-up and operating normally.
(which includes running a Power On Self Test).
The Switch has failed its Power On Self Test.
Refer to Chapter 4 Solving Problems Indicated by LEDs.
The Switch is not receiving power or there is a fault with the
Power Supply Unit.
Interface to flash.
The Switch Alert LED has been configured via the CLI or Web
Interface to be off (Default state).
Supply Data Warning Label
Console
(max) 19200,8,1,N
Console Port
