- Page 1 ORIGINAL INSTRUCTIONS Sliding Compound Mitre Saw RMS254DB...
- Page 2 Important! It is essential that you read the instructions in this manual before assembling, operating and maintaining the product. Subject to technical modification.
-
Page 3: Electrical Safety
Safety, performance, and dependability have been given Water entering a power tool will increase the risk of top priority in the design of your mitre saw. electric shock. Do not abuse the cord. never use the cord for ■ IntenDeD uSe carrying, pulling or unplugging the power tool. - Page 4 ■ Disconnect the plug from the power source and/ and push the saw through the workpiece. Cutting on or remove the battery pack, if detachable, from the pull stroke is likely to cause the saw blade to climb the power tool before making any adjustments, on top of the workpiece and violently throw the blade changing accessories, or storing power tools.
- Page 5 hand into the blade. ■ Ensure the saw blade is mounted correctly, tighten the arbor nut securely before use (tightening torque approx. let the blade reach full speed before contacting the ■ 7-12 Nm). workpiece. This will reduce the risk of the workpiece being thrown.
- Page 6 correctly. harmful to health. Use a dust suction system and wear a suitable dust protection mask. Remove deposited ■ The lower blade guard should only open when the dust thoroughly with a vacuum cleaner. blade is lowered to the workpiece and must always be able to move freely and close automatically.
- Page 7 waRnInG waRnInG Dust from certain paints, coatings and materials may For greater safety and reliability, all repairs should be cause irritation or allergic reactions to the respiratory performed by an authorised service centre. system. Dust from wood such as oak, beech, MDF and others are carcinogenic.
- Page 8 SyMBolS on tHe pRoDuCt Laser radiation. Class 2 laser product λ: 650nm; P≤1mW Safety alert IEC 60825-1:2014 Regulatory Compliance Mark Adjust the position of sliding (RCM). Product meets applicable fence before performing bevel regulatory requirements. cuts. Please read instructions carefully before starting Waste electrical products should...
- Page 9 2 mm 4 mm 5 mm D13 x D8 x 1.6mm...
- Page 10 1. Handle, insulated gripping surface 19. Mounting hole x 4 2. Power switch 20. Workpiece support x 2 3. Safety lock lever 21. Blade 4. Upper guard 22. Laser switch 5. Lower guard 23. Spindle lock button 6. Sliding fence x 2 24.
- Page 11 22 23...
- Page 14 p.14 p.14 p.15 p.15 p.16 p.17 p.18 p.21...
- Page 15 90˚ 90˚ 45˚ p.25 p.32 p.34 90˚ 90˚ p.26 p.37 p.28 p.31 p.39...
- Page 16 90º 90º...
- Page 17 4 mm 4 mm...
- Page 20 0˚/15˚/22.5˚/ 30˚/45˚...
- Page 23 0˚/15˚/22.5˚/ 30˚/45˚...
- Page 24 4 mm...
- Page 26 4 mm...
- Page 29 2 mm...
- Page 34 90˚ 90˚ 0˚...
- Page 35 90˚ 90˚ =90˚ ≠90˚...
- Page 36 45˚ 45˚ 0˚ 4 mm...
- Page 38 =45˚ ≠45˚...
- Page 39 90˚ 90˚ 0˚ 4 mm...
- Page 40 5 mm 5 mm 90˚...
- Page 41 5 mm 5 mm 4 mm 4 mm...
- Page 42 90º...
- Page 44 Mitre saw The declared noise emission value(s) have been measured Model RMS254DB in accordance with a standard test method of EN 62841-1 Net weight 17.7 kg and EN 62841-3-9, and may be used for comparing one tool with another.
- Page 45 tRouBleSHootInG pRoBleM poSSIBle CauSe SolutIon Mitre saw will not start. No power to the saw. Check that the power cord is connected to a live power source. Wood burns at ends of cut. Dirty blade. Clean blade. Worn blade. Replace worn blade. Workpiece is binding.
- Page 48 techtronic Industries australia pty ltd 31 Gilby Road, Mount Waverley, VIC 3149, Australia techtronic Industries n.Z. limited 2 Landing Drive, Mangere Auckland, 2022, New Zealand 20180910v1b...
