6. Install the filter cup to its original
position after checking that the fil-
ter, spring and O-ring are located
in their proper positions. You can
bleed more easily by assembling
the filter cup after filling clean fuel
to two thirds of its level.
7. Turn the fuel cock to the aIR side
and crank for several seconds until
the filter cup is filled.
8. Check for leakage by turning the
cock to the ON position and start-
ing the engine when the fuel is
filled up to 80% of the filter cup.
9. If engine cannot be started, this
could be due to air in the fuel line.
bleed the fuel line, referring to
"bleeding fuel line".
UD200(K9 2400)-유럽향-07.indd 19

BLeeDINg FUeL LINe (m)

The fuel line for the KIOTI engine is designed to be bled automatically. If the
engine still cannot be started even after 4~5 times of cranking, bleed as fol-
lowed:
Do not crank the engine for more than 5 seconds continuously at a time to
protect the start motor and battery.
(1) Fuel Tank
(2) Fuel Filter
(3) Fuel Injection Pump
(4) Injection Pipe (7) Fuel Feed Pump
(5) Injection Nozzle (8) bleeding bolt
(6) Fuel Overflow Pipe (Hose)
(9) Nozzle holder Nut
7
MaINTENaNCE
-19
