Operating The Unit - Boss Phase Shifter PH-3 Owner's Manual

Operating the Unit

2, 4 2, 5
1. When you have finished making the connections
(p. 6), press the pedal switch to turn the effect on.
(the CHECK indicator is lit).
2. Set the RATE, DEPTH, and RES knobs at the center
position.
3. Use the STAGE switch to select the stage type.
8
2, 6 3
4. With the RATE knob, adjust the speed of the filter
change.
* When set to MIN, the filter remains off.
5. With the DEPTH knob, adjust the depth of the filter
change.
* The filter effect stops when this is set to MIN with the STAGE
switch set to anything besides FALL or RISE.
6. With the RES (Resonance) Knob, adjust the strength
of the filter effect.
* Raising the RES setting (turning it clockwise) makes it easier
for the sound to become distorted. If it appears that the sound
is becoming distorted, try lowering the RES setting.
