- Page 1 USER GUIDE 10" Dual Screen Portable DVD Player NS-DD10PDVD19 Before using your new product, please read these instructions to prevent any damage.
-
Page 2: Table Of Contents
NS-DD10PDVD19 Contents Introduction ............3 IMPORTANT SAFEGUARDS . -
Page 3: Introduction
10" Dual Screen Portable DVD Player Introduction Congratulations on your purchase of a high-quality Insignia product. Your NS-DD10PDVD19 represents the state of the art in DVD player design and is designed for reliable and trouble-free performance. IMPORTANT SAFEGUARDS Read these instructions. -
Page 4: Safety Precautions
NS-DD10PDVD19 Handling the LCD panel • Never place heavy or sharp objects on the LCD panel or frame. • Your DVD player’s screen is made of glass. Do not drop your player or hit, jolt, or press hard against the LCD panel. If the screen breaks, be careful of broken glass. -
Page 5: Features
10" Dual Screen Portable DVD Player WARNING: Chemical Burn Hazard. Do not ingest the battery. • The remote control supplied with your DVD player contains a coin/button cell battery. If the battery is swallowed, it can cause severe internal burns in just two hours and can lead to death. -
Page 6: Front
NS-DD10PDVD19 Front BUTTON DESCRIPTION Power indicator Lights blue when your DVD player is turned on. Point the remote control towards the remote sensor Remote sensor on the front of your DVD player. In playback mode, press to skip back on a disc. Press and hold to decrease the volume. -
Page 7: Top And Sides
10" Dual Screen Portable DVD Player Top and sides open ITEM DESCRIPTION Slide to open the disc tray. OPEN latch Slide to turn your player on or off. ON/OFF switch Plug headphones into this jack. (headphone out) jack Connect either the AV connecting cable to this jack to share playback with the other DVD player AV OUT jack or the AV adapter cable to view playback on a TV... -
Page 8: Back
NS-DD10PDVD19 Back ITEM DESCRIPTION Slide the mounting straps through these slots Strap slots when installing your player in a vehicle. Pull out to set your player on a desktop or table. Stand www.insigniaproducts.com... -
Page 9: Remote Control
10" Dual Screen Portable DVD Player Remote control Your players come with two remote controls, labeled A and B. Your players are also labeled A and B on the fronts. Make sure that you use the correct remote control for the player you are using. Notes: •... - Page 10 NS-DD10PDVD19 BUTTON DESCRIPTION During DVD playback, selects a subtitle language, if available SUBTITLE on the DVD. During DVD playback, selects a viewing angle, if available on ANGLE the DVD. TITLE Returns to the title menu on a DVD. ENTER Confirms selections.
-
Page 11: Setting Up Your Dvd Player
10" Dual Screen Portable DVD Player BUTTON DESCRIPTION (skip Goes to the next chapter or track. forward) (skip Goes to the previous chapter or track. reverse) Press to fast-forward on a disc. Each time you press this button, (forward) the speed changes (2x to 4x to 8x to 16x to 32x to normal playback). -
Page 12: Connecting To Ac Power
NS-DD10PDVD19 Connecting to AC power CAUTIONS: • The AC adapter is used to disconnect your player from AC power. When the AC adapter is plugged into a power outlet, your player is not completely disconnected from power, even when the power is turned off. -
Page 13: Connecting Your Dvd Players
10" Dual Screen Portable DVD Player Connecting your DVD players Plug the AV connecting cable to the AV OUT jack on one player and to the AV IN jack on the other player. Note: The player with the AV OUT connection is the master player, and the player with the AV IN connection is the secondary player. -
Page 14: Connecting Headphones
NS-DD10PDVD19 Slide the horizontal straps A and B through the slots on the back of the DVD player, then fold and secure them onto the back of the headrest mount. Fit the straps E1, E2, F1, and F2 around the headrest and thread them through the plastic buckles. -
Page 15: Connecting To A Tv Or Monitor
10" Dual Screen Portable DVD Player Connecting to a TV or monitor You can connect your player to a TV or monitor so you can watch DVDs or view photos on the TV or monitor. Plug the AV adapter cable into the AV OUT jack on your DVD player. ON OFF ON OFF AV OUT... -
Page 16: Controlling Dvd Or Audio Cd Playback
NS-DD10PDVD19 Slide the OPEN switch. The front and back of your player separate to give access to the disc tray. Place a disc, label side up, in the disc tray, then press the player front and back together until you hear a click. The disc starts playing automatically. -
Page 17: Using Zoom Mode
10" Dual Screen Portable DVD Player To resume normal playback, press PROGRAM, then select the STOP. Press PROGRAM again to close the PROGRAM menu. Using zoom mode You can enlarge or shrink the picture displayed on the screen. • For a DVD, press ZOOM during playback or still playback to activate the Zoom function. -
Page 18: Selecting The Audio Mode
NS-DD10PDVD19 • 16:9: wide screen display: Select this option to play wide-screen videos on a wide-screen TV. Notes: • The visible picture size is preset on a DVD. Therefore the playback picture of some DVDs may not conform to the picture size you select. -
Page 19: Adjusting Video Options
10" Dual Screen Portable DVD Player Adjusting video options Press SETUP. Press to select VIDEO, then press ENTER. - - VIDEO SETUP PAGE - - BRIGHTNESS CONTRAST SATURATION GOTO VIDEO SETUP PAGE Press to select an option, then press to adjust the setting. -
Page 20: Setting Video And Audio Preferences
NS-DD10PDVD19 Setting video and audio preferences Note: You can only access the PREFERENCE PAGE when there is no disc in the disc tray. Press SETUP. to select PREFERENCE, then press ENTER. - - PREFERENCE PAGE - - TV TYPE... -
Page 21: Using Parental Controls
10" Dual Screen Portable DVD Player • PASSWORD—Lets you create or change a parental control password, or lets you turn the password feature on and off. See Setting up a parental control password on page 21. • DEFAULT—Resets all options to the default settings. Press ENTER to save your setting, then press SETUP to close the menu. -
Page 22: Changing The Parental Control Password
NS-DD10PDVD19 Press to select PASSWORD, then press ENTER. - - PASSWORD SETUP PAGE - - PASSWORD MODE PASSWORD CHANGE GOTO PASSWORD SETUP PAGE Use your remote control to enter a four-digit password, then enter the password again. Note: The master password is 1369. If you forget your password, you can enter the master password. -
Page 23: Setting A Parental Control Rating
10" Dual Screen Portable DVD Player Press to select PASSWORD, then press ENTER. OLD PASSWORD NEW PASSWORD CONFIRM PWD Use your remote control to enter the old four-digit password, enter the new password, then enter the new password again. Note: If you forget your password, use the master password (1369) for the old password. -
Page 24: Cleaning Discs
NS-DD10PDVD19 Cleaning discs • Before playback, wipe the disc outwards from the center with a clean cloth. Troubleshooting PROBLEM SOLUTION No power • Make sure that the AC adapter is plugged in and connected. • Make sure that your player is turned on. -
Page 25: Specifications
10" Dual Screen Portable DVD Player Specifications Specifications subject to change without notice. Compatible discs DVDs (Region 1 for U.S.), Audio CDs, and MP3 discs Signal system PAL or NTSC 10 inches Frequency response 20 Hz to 20 kHz Audio S/N >... -
Page 26: One-Year Limited Warranty
Product is determined to be defective by an authorized Insignia repair center or store personnel, Insignia will (at its sole option): (1) repair the Product with new or rebuilt parts; or (2) replace the Product at no charge with new or rebuilt comparable products or parts. - Page 27 • Damage due to incorrect operation or maintenance • Connection to an incorrect voltage or power supply • Attempted repair by any person not authorized by Insignia to service the Product • Products sold “as is” or “with all faults”...
- Page 28 1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico) INSIGNIA is a trademark of Best Buy and its affiliated companies. Distributed by Best Buy Purchasing, LLC 7601 Penn Ave South, Richfield, MN 55423 U.S.A. ©2018 Best Buy. All rights reserved. Made in China...
