RoboSHOT 12 and 30 HDBT Cameras
Current Release
RoboSHOT® 12/30 HDBT 3.1.0
May 13, 2019
In the admin web interface, various camera behavior settings have moved from soft DIP switches to the
General tab of the System page.
Some parameters were incorrectly stored in CCU scenes and in presets stored with color information.
This has been fixed.
Executing several pan, tilt, or zoom to absolute position commands in quick succession could generate
error messages. This has been fixed.
When changing camera settings from a connected device, in some cases the camera's web interface did
not immediately reflect the change. This has been fixed.
In some cases, the web interface did not load properly if the computer had recently accessed another
Vaddio device at the same IP address. This has been fixed.

Release History

RoboSHOT 12/30 HDBT 3.0.1
February 15, 2019
Added support for RTMP streaming. This is configured in the admin web interface and can be
enabled/disabled in both the admin and the user web interface.
Improved handling of HDMI hot-plug events.
Improved camera behavior during lengthy camera operations.
Improved camera behavior when an operator rapidly and repeatedly cancels and restarts camera
operations.
RoboSHOT 12/30 HDBT 1.3.0
November 16, 2018
Support for UVC proxying from a OneLINK Bridge to enable far-end control when used with some third-
party soft codec clients like Zoom that support UVC standards.
One Push White Balance can now be executed through the web interface.
HTTPS access to the camera is now supported and the HTTPS certificate can now be configured from
the admin web interface.
HTTP access to the camera can now be disabled by an admin. When this is disabled, HTTPS must be
used to connect to the web interface.
Added ability for the administrator to disable the camera's Telnet server through the web interface.
Support for DNS Service Discovery.
Initial public REST API.
Soft DIP in admin web interface to turn off the camera's LED during standby instead of displaying its
normal standby color.
Telnet command to allow Streaming Enabled status to be toggled: [streaming ip enable toggle]
RELEASE NOTES
& UPDATE INSTRUCTIONS
Page 1 of 7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RoboSHOT 12 and is the answer not in the manual?

Questions and answers

Summary of Contents for VADDIO RoboSHOT 12

  • Page 1 This has been fixed. In some cases, the web interface did not load properly if the computer had recently accessed another • Vaddio device at the same IP address. This has been fixed. Release History RoboSHOT 12/30 HDBT 3.0.1...
  • Page 2 Added Codec Control Mode for Polycom® 3xx/5xx/7xx series codecs. • • Added Codec Control Mode for Cisco® sX20 and SX80 series codecs. (Note: for SX20 codecs, Vaddio recommends the codec’s firmware be updated to latest “CE” series firmware for best operation). •...
  • Page 3 Updated for wide dynamic range setting over RS-232. • RoboSHOT 12/30 HDBT 1.0.1 January 19, 2017 Improvements • Corrected motor configuration on RoboSHOT 12 HDBT units home position. Updated default IP streaming setting to "720p Better". • RoboSHOT HDBT 12/30 1.0.0 November 28, 2016 Notes Initial release.
  • Page 4 Firmware Update Instructions – RoboSHOT HDBT Requirements Network access to the RoboSHOT HDBT camera. • The web interface’s admin password, if it has been changed from factory default. • The .p7m firmware file for the RoboSHOT HDBT camera (found on the RoboSHOT HDBT product page’s •...
  • Page 5 4. Navigate to the Systems tab within the web pages and select Choose File. 5. Browse to the RoboSHOT HDBT firmware file that you downloaded and select it. Page 5 of 7...
  • Page 6 Verify the correct firmware file is displayed, then select “Begin Firmware Update”. 7. A confirmation pop-up and warning will be displayed. Please read and completely understand the pop-up warnings, as it is easy to lose patience waiting for updates. Please read the warnings regarding the interruption of power below.
  • Page 7 Vaddio, the Vaddio logo and RoboSHOT are trademarks or registered trademarks of Legrand AV Inc. All other brand names or marks are used for identification purposes and are trademarks of their respective owners.
