Alarm Lock 715 Quick Start

345 Bayview Avenue
Amityville, New York 11701
For Sales and Repairs 1-800-ALA-LOCK
For Technical Service 1-800-645-9440
Publicly traded on NASDAQ Symbol: NSSC
© ALARM LOCK 2007
PLUG-IN STYLE 120VAC / 12VAC
OPTIONAL 277VAC / 12VAC TRANSFORMER
PROVIDES OVERRIDE TO DELAYED
EGRESS DURING FIRE ALARM
(VON DUPRIN EPT-10) POWER TRANSFER FROM DOOR TO
FRAME SUPPLIED BY CONTRACTOR. NOTE FRAME AND
DOOR MUST BE PREPARED FOR THIS HARDWARE
CONCEALED WIRING DETAIL
TRANSFORMER (SUPPLIED)
--OR--
(ALARM LOCK PART #277-12)
HIDDEN WIRES IN
DOOR
MORTISE 7-PIN CYLINDER SUPPLIED BY GENERAL
CONTRACTOR, INSTALLED BY AN EXPERIENCED,
QUALIFIED AND TRAINED TECHNICIAN

QUICK START

PUSH BAR MODEL 715
FIRE ALARM
RELAY
(PANEL)
POWER FROM A 24 HOUR EMERGENCY
LIGHTING CIRCUIT (CRITICAL POWER)
12VAC
MODEL 715 CONTROL BOX
ARMORED CABLE
5 CONDUCTOR 22 AWG (SUPPLIED)
HIDDEN WIRES
IN DOOR
DOOR SIGN
(SUPPLIED)
WI1584 1/07
