STEP 3: Preparation of the wall sleeve
installed, proceed as follows:
on each side of the to provide a level installation.
Install the screws from the outside of the wall sleeve.
NOTE: Do not drill any holes in bottom of the wall sleeve.
Wall Sleeve
Roomside
Case angle
(field-supplied)
Block
Installation Instructions
Brick
STEP 4: Installation of the wall sleeve in
the wall opening
itate easy installation of an accessory drain, if desired. (If it
applied between the drip rail and wall sleeve.)
IMPORTANT:
Install wall sleeve level from side to side with a slight tilt
from front to rear. Use a level; no more than a 1/4" bubble
will be the correct wall sleeve slant to the outside.
For an internal drain, install level from front to rear.
the bottom of the wall sleeve.
bolts, etc. to attach the wall sleeve to the wall structure.
Secure case through
side and / or top only
side and/or top only
2" min. from
case bottom
sleeve bottom
the wall sleeve.
NOTE: Do not drill any holes in the wall sleeve for electrical
connections.
3
Inside wall
Inside wall
-
