DC side
AC side
Figure 2: FW250 Enclosure
Unthreaded standoffs for attaching to FX
Unthreaded standoffs insert
into the AC or DC end of the FX
Inverter/Charger's top casting
mounting holes.
Bottom 2" knockout
Figure 3: FLEXware 250 top view
Ground Bus Bar
