Getting to Know FLEXware 50
When mounting the FLEXware 250, the various breaker
slots must be in a vertical (forward facing) position
and cannot face downward or upward. Otherwise, the
breakers can malfunction.
The FLEXware 250 also accommodates a shelf
or flat surface mounting as long as no breaker
slots are facing downward or upward.
DC Breaker Guard
Figure 1: FLEXware 250
FLEXware 250 mounted
as an AC enclosure
FLEXware 250 mounted
as a DC enclosure (shown
with cover plate)
5
