- Page 1 TM360 TEMP-SEEKER ® PRECISION THERMO-PSYCHROMETER OPERATION MANUAL 1.800.561.8187 information@itm.com www. .com...
-
Page 2: Table Of Contents
GENERAL INFORMATION Table of Contents General Information Unit Operation TMX3RH Method Wet-Sock Method Psychrometric Chart Accessory Probes 10-12 Warranty & Contact Information TM360 Overview The TM360 TEMP-SEEKER is a high resolution thermo-psychrometer adaptable to ® accommodate all your temperature, humidity, dry/wet bulb and dew point measurements. The instrument offers 4 separate temperature channels for high accuracy thermistor probes, and an auxiliary port to connect a state of the art solid state RH / DB probe. -
Page 3: General Information
GENERAL INFORMATION TM360 Unit Specifications Resolution ±0.1˚F or ˚C ±0.4˚F / ±0.2˚C from 14.0 to 158˚F / -10.0 to 70˚C; 0.6˚F / Temperature Accuracy 0.3˚C elsewhere in the range RH Range 0 to 100%RH RH Accuracy (TMX3RH) ±1.8%RH from 10 to 90%RH; ± 3% elsewhere in the range ±1.2% of reading ±... -
Page 4: Unit Operation
UNIT OPERATION 1.800.561.8187 information@itm.com www. .com... - Page 5 UNIT OPERATION FUNCTION Press to turn ON, press and hold for 3 sec. to turn OFF A, B, C, D Press to display probe measurement of that channel Press to display relative humidity, dry bulb, wet bulb or dew RH,DB,WB,DP point temperatures.
- Page 6 Turning the instrument ON and Off: Press the key to turn the instrument on; the LCD will initially display all characters, the software version used (CPS 110 or similar) and whether the automatic power off feature is enabled or not (APO ON or APO OFF). The instrument will then default to displaying the measurement read in channel A.
-
Page 7: Tmx3Rh Method
TMX3RH METHOD The TMX3RH is a high accuracy silicon device for the measurement of relative humidity and dry bulb temperature. Both sensors are integrated in one small silicon chip, factory calibrated and conditioned to give accurate and fast reponse. The TM360 uses this accurate data to compute the wet bulb and the dew point temperatures using the latest software algorithms. -
Page 8: Wet-Sock Method
WET-SOCK METHOD This method can be used to obtain relative humidity, dry/wet bulb and dew point mea- surements using two standard TMX2G temperature probes and channels A and B. There are two options for Step 4. Both options provide accurate readings and are merely a method of user preference. -
Page 9: Psychrometric Chart
PSYCHROMETRIC CHART Psychrometry is the science which studies the properties of moist air. A psychrometric chart graphically illustrates the relationship between air temperature and relative humid- ity as well as other properties. Air Temperature is a measure of the heat content of air. Three different temperature measurements are used in the pychrometric chart. -
Page 10: Accessory Probes
ACCESSORY PROBES / ACCESSORIES Models TM360 Includes: TMX2A (1) TMX2G (1) TMX2S (1) TM360A Includes: TMX3C (1) TMX2GA (1) TMX2FP (1) TM360C Includes: TMX2A (1) TMX3C (1) TMX2S (1) Accessories TMX3PS Optional A/C power supply (100-240V) TMX3WB 6pk of 2" cotton socks for use with the Wet Sock Method (pg.8) TMX2A Moving Air Probe All probes have 15ft / 4.5m leads Probe Type... - Page 11 ACCESSORY PROBES / ACCESSORIES TMX2G General Purpose Probe All probes have 15ft / 4.5m leads Probe Type Surface / Air / Liquids Common Uses Copper pipe / Ambient Air / RH wet-sock method Response Time 6 seconds Range -40˚F to 257˚F / -40˚C TO +125˚C TMX2GA General Purpose Air Probe All probes have 15ft / 4.5m leads Probe Type...
- Page 12 ACCESSORY PROBES / ACCESSORIES TMX3RH RH/DB/WB/DP Probe (TM360) All probes have 15ft / 4.5m leads Probe Type Specialty RH probe Common Uses Measuring indoor air quality, setting/troubleshooting humidity devices Response Time 10 seconds in moving air, 20 seconds in still air Temperature -40˚F to 194˚F / -40˚C TO +90˚C Range...
-
Page 13: Warranty & Contact Information
All repaired equipment will carry an independent 90-day warranty. This repair policy does not include equipment that is determined to be beyond economical repair. Contact Us CPS Products, Inc. 1.800.561.8187 information@itm.com www.
