Summary of Contents for zika I-PLAS25 II
-
Page 3: Table Of Contents
CONTENTS 1. Contents ............................... 1 2. Safety warning ............................. 2 3. Machine description ..........................7 4. Technical parameters table ........................8 5. Operation and panel function instruction .................... 9 6. Installation instruction ......................... 10 7. Notes or preventive measures ......................12 8. -
Page 4: Safety Warning
SAFETY WARNING ● Please read this manual carefully before using it. ● The safety notes listed in this manual is to ensure correct use of the machine and to keep you and other people from being hurt. ● The machine is safety considered designed, please refer to the safety warning listed in the manual when using it in case of bad accidents. - Page 5 people with safety knowledge and technique to operate the machine. Danger! Please follow the rules below in case of electric shock: ＊Any contact of electric parts may cause fatal electric shock or burnt. 1. Don’t touch any electric parts. 2. Ask professional person to connect the machine and workpiece to the ground. 3.
- Page 6 5. Do not weld in degrease, washing and spray space. 6. Use breathe preventive facilities as it will cause poisonous dust and gas when weld shielded steel. Danger! Please follow the below notes to avoid accidents like fire and explode: ＊Spark and hot workpiece can cause fire.
- Page 7 1. Use the gas cylinder correctly. 2. Use the equipped or recommended gas adjustment. 3. Read the manual of the gas adjustment carefully before using it, and pay attention to the safety notes. 4. Fix the gas cylinder with appropriative holder and other relative parts. 5.
- Page 8 5. If the machine is equipped with gas cylinder and wire feeder, download them from the power source and ensure the horizontal of the machine. Do fix the gas cylinder with gallus or chain when moving it in case of body hurt. 6.
-
Page 9: Machine Description
MACHINE DESCRIPTION The welding machines are rectifiers adopting the most advanced inverter technology, which can apply in plasma cutting system of using pressing air. The development of inverter welding equipment benefits from the development of the inverter power supply theory and components. -
Page 10: Technical Parameters Table
TECHNICAL PARAMETERS TABLE Model I-PLAS25 Ⅱ Parameters 3 phase～AC380V Input voltage（V） 15% Rate input current（A） No-load voltage（V） Current Range（A） 20-80 Rate output voltage（V） Duty cycle（%） Efficiency（%） Power factor 0.93 Insulation Class Housing Protection Class IP21 Arcing Way Untouched Pressure of air compressor （KG）... -
Page 11: Operation And Panel Function Instruction
OPERATION AND PANEL FUNCTION INSTRUCTION Open the power switch of front panel, make the power switch is on “on” position .At this time indicator of power switch is on .Screen will show the current volume. Adjust the gas pressure to be adequate to machine, open the valve of pressed air. Press the control knob of torch, electromagnetic valve is starting ,sound of HF arc-striking can be heard and burner of torch should flow out gas (Burner of arc-supporting cutter should spurt fire ) It is 1mm from copper tip to work piece (it is further if it is arc-supporting cutter), press knob of torch and burn and... -
Page 12: Installation Instruction
INSTALLATION INSTRUCTION The machine is equipped with power voltage compensation device. When the power voltage fluctuates between±15% of rated voltage, it still can work normally. When the machine is used with long cables, in order to prevent voltage form going down, bigger section cable is suggested. - Page 13 Air regulator installation and operation Firmly tight and seal the copper air hole at IN and OUT terminal. By high pressure rubber tube firmly. Tight and seal the meter with meter face rubber tube. Fix the connecting shelf with screw as the regulator position. Get down the plastic screw and fix the regulator on the shelf.
-
Page 14: Notes Or Preventive Measures
NOTES OR PREVENTIVE MEASURES 1. Environment 1） The machine can perform in environment where conditions are dry with a dampness level of max 90%. 2） Ambient temperature is between -10 to 40 degrees centigrade. 3） Avoid welding in sunshine or drippings. Do not let water enter the gas. 4）... -
Page 15: Questions To Be Run Into During Welding
QUESTIONS TO BE RUN INTO DURING CUTTING Fittings, welding materials, environment factor, supply powers maybe have something to do with welding. User must try to improve welding environment. A、 Cutting surface is rough, poor cutting result: The machine may be not well operated. You can check it as follow: ）, and its range Make sure the compressed air supply has enough pressure which is not less than 0.3MPa（3Kg/cm is±0.05Mpa. -
Page 16: Maintenance
MAINTENANCE WARNING： Power must be turned off for all checking and maintenance, before opening the housing, make sure the power plug is disconnected. Remove dust by dry and clean compressed air regularly, if welding machine is operating in environment where is polluted with smokes and pollution air, the machine need removing dust everyday. -
Page 17: Notes Before Checking
NOTES BEFORE CHECKING WARNING! Blind experiment and careless repair may lead to more problems and make formal check and repair more difficult. When the machine is electrified, the bared parts contain life-threatening voltage. Any direct and indirect touch will cause electric shock, and severe electric shock will lead to death. -
Page 18: Troubleshooting And Fault Finding
TROUBLESHOOTING AND FAULT FINDING Notes: The following operations must be performed by qualified electricians with valid certifications. Before maintenance,please contact with us for professional suggestion. Fault symptom and solutions of I-PLAS25 Ⅱ: Faults Solutions 1. Make sure air switch is on. Meter can not display, fan can not 2.
