Description of the lamp status
Refer to the below table for the meaning of the lamp status.
► Fig.9: 1. Wireless activation lamp 2. Channel number indicator 3. Caution lamp
Lamp
Status
Wireless
Standby
activation
lamp
Tool
registration
Cancelling/
erasing
tool
registration
Others
Channel
Channel
number
number
indicator
selection
Testing
Caution
Overheated
lamp
or other
trouble
Color
On
Blinking
Blue
Green
Red
(slow: 2 times/sec.)
(fast: 5 times/sec.)
Red
Off
-
Green
Green
Red
Duration
Adaptor: con-
Waiting for the tool registration or the wireless
tinuing
activation function is available.
Tool: 2 hours
The lamp on the adaptor blinks when the stand-by
switch on the vacuum cleaner is set to "AUTO" or
equivalent.
The lamp on the tool blinks when the wireless
activation button is pushed. The lamp on the tool
will automatically turn off when no operation is
performed for 2 hours.
When the tool is
The wireless activation of the vacuum cleaner is
running.
available and the tool is running.
20 seconds
Ready for the tool registration. Searching the tool to
be registered.
2 seconds
The tool registration has been finished. The wireless
activation lamp will start blinking in blue.
20 seconds
Ready for the cancellation of the tool registration.
Searching the tool to be cancelled.
When the
Ready to erase all tool registrations.
wireless acti-
vation button is
pressed down.
2 seconds
The tool registration has been cancelled/erased.
The wireless activation lamp will start blinking in
blue.
3 seconds
The power is supplied to the wireless unit and the
wireless activation function is starting up.
-
The stand-by switch on the vacuum cleaner is not
set to "AUTO" or equivalent.
Continuing
The lighted channel number is selected.
15 seconds
The adaptor is testing the communication to the
vacuum cleaner through the selected channel
number.
Continuing
The adaptor is overheated or in other trouble.
Unplug the adaptor from the vacuum cleaner. Clean
the vents on the adaptor and cool it down for a while
and then check if it works properly.
If the adaptor does not work properly, contact our
authorized service center for repairs.
7 ENGLISH
