- Page 1 EVMK2E Evaluation Module Quick Start Guide ©2014 Texas Instruments Incorporated...
-
Page 2: Evaluation Module
COM1 : SoC UART Console 1111 : No Boot mode/JTAG DSP Little Endian 0010 : NOR SPI ARM Master Boot USB3 PORT 1(Device and HOST Modes) USB control of both SOC COM1 & BMC COM2 USB3 PORT 0(HOST only) ©2014 Texas Instruments Incorporated... - Page 3 Please download driver from any of below link as per Linux kernel version on PC. Compile the driver and install it. http://www.silabs.com/Support%20Documents/Software/Linux_3.x.x_VCP_Driver_Source.zip http://www.silabs.com/Support%20Documents/Software/Linux_2.6.x_VCP_Driver_Source.zip Ensure EVM configuration switches are set as shown for NOR SPI Boot. Connect the USB mini-B cable to J1 ©2014 Texas Instruments Incorporated...
- Page 4 Insert DC-in cable to apply 12V power. On SoC serial port console a display will be seen, as shown in image. Hit any key to stop auto-boot when prompted. EVM is now ready for Uboot applications. MCSDK Downlink Page http://software-dl.ti.com/sdoemb/sdoemb_public_sw/mcsdk/latest/index_FDS.html ©2014 Texas Instruments Incorporated...
- Page 5 Insert DC- - in cable to apply in cable to apply 12V power. 12V power. Launch Launch CCS CCS. . After CCS is After CCS is opened, opened, EVM is now rea EVM is now ready for use. for use. ©2014 Texas Instruments Incorporated...
- Page 6 Fax :+91-79-2656 0722. does not constitute TI's approval, warranty or endorsement thereof. http://www.einfochips.com/ The floating bar is a trademark of Texas Instruments. All other trademarks are the property of their respective owners ©2014 Texas Instruments Incorporated...
