- Page 1 USER MANUAL KWW36W1RGB...
-
Page 2: Table Of Contents
I n d e x summarize ................3 safety instruction ..............3 outside size picture ............... 4 main function ................ 5 DMX controller function............5 Display operation instruction ..........6 Manual instruction..............6 Operating control instruction ..........8 XRL connection instruction............ 9 Connection picture .............. -
Page 3: Summarize
The built-in program includes dimmer, strobe, eotic, gradual change, fading and so on. International standard DMX 512 signal is requested. Packing list • KWW36W1RGB light PC （ Waterproof Power in/out extension Cable ， Waterproof DMX in/out extension cable ） • Waterproof Power in Cable 1PC（with Plug）... -
Page 4: Outside Size Picture
Safety instruction ● Make sure the power supply voltages are consistent with this lights，Ensure the use of voltage is in the range of the request technical parameter. ●before the installation, please check the light’s fasteners and mechanical structure have been received in good condition and appear no damage. ●This light is designed for indoor or outdoor, working temperature is lower than 40 degree. -
Page 5: Main Function
Main Function • Protection rating: IP65, in door or out door used. • the unique design of the cooling way: the light source is separately with the electrical source and natural air convection cooling • DMX512 Controller，DMX ID address with 3 digitals display •... -
Page 6: Display Operation Instruction
Display Operation DC24V/OUT AC 100V-240V (power in) A：function button B：setup button Menu Instruction 1. “A” is the function button “B” is the setup button. correspond with DMX and built-in program mode. DMX mode: When shows all of the figures (001-512), for the light’s DMX address code, receive DMX512 signal. - Page 7 adjust tens-digit as 0-9 press “A” thirdly, the left third digit flashing, then press “B” to adjust ones-digit as 0-9 press “A” fourthly, switch to built-in program mode, the display’s first word on the left show “P” ,the second for the built-in programs and flashing, press “B”...
-
Page 8: Operating Control Instruction
4. When the screen flashes, it indicates that in the set-state. If you do not press any key for 8 seconds, the state will saved automatically, and when you turn on the lights next time will show this state. Operating Control Instruction Master/Slave Master：The master should set as built-in program and shows”... -
Page 9: Xrl Connection Instruction
： ， Noted In order to avoid failures and interference signal transmission （ ） connect a resistance120Ω 1/4W at the end of the DMX connecting as below: The Conversion between 3pin and 5 pin XLR If the output cable of DMX512 controller is the 5PIN, please use 1pc 5PIN to 3PIN cable... -
Page 10: Connection Picture
Connecting picture Cable connecting picture... -
Page 11: Exploded Views
Exploded views... -
Page 12: Luminance List
Illuminant list... -
Page 13: Problem Analyze
Problem Analysis Problem Checking way Check the power source plug is in normal or not Can not turn on Check the switch of the lights is off or on the light Check it the fuse if in normal Check the DMX cable is connect to the lights or not DMX can not Check the DMX512 controller work in normal or not control it... - Page 14 parallel, so please check if the leds is loose Some of the LED Use the multi meter to check if the led is bright or not light not, of not, please change the led check whether current limiting resistor is normal or Check constant current IC is normal or not (compared with the normal IC) Single color leds...
-
Page 15: Technical's Specification
Technical Specification ● Input voltage：AC 170V-264V/47-63HZ ● Output voltage：DC24V ● Consume：50W ● Lamp Type：High Power LED (1W) ● Lamp Spec：R（12PCS）、G（12PCS）、B（12PCS） ● Control Signal：DMX512, Master/Slave ● Control mode：stand alone/ DMX/ master and slaver ● Channel： 6CH ● Color effect：R、G、B mixing ● Function Effect： ： ： ： dimmer, strobe, water, gradual change ●... - Page 16 Copyright 2012 KANDOLITE. All rights reserved. Due to continuous improvements and innovations, specifications may change without notice.
