User Manual
PLUS+1® Compliant OX024-x10 Function Block
OX024-x10 Function Block
Signal
Type
CurChgLim
U16
DitherFreq
U16
ReqFreq
U16
Outputs – Digital Outputs
Signal
Type
Pin _MFOut
Bus
Config Bus
DefOutputValue BOOL
DigOut BOOL
Outputs – MultiFunction Outputs
Signal
Type
Pin _MFOut
Bus
Config Bus
PinConfig U16
DefPinConfig U16
DefOutputValue U16
©
Danfoss | July 2018
Direction
Range
Output
22 – 333
Output
40 – 250
Output
30 – 4000
The output status of digital outputs on connectors and pins C1p06, C1p07, C1p08, C1p09, C1p10, and
C1p11 is described.
Direction
Range
——
——
——
——
Output
——
Output
——
The output status of multifunction outputs on connectors and pins C1p12, C2p01, C2p02, C2p03, C2p04,
C2p05, C2p06, C2p07, C2p08, and C2p09 is described.
Direction
Range
——
——
——
——
Output
0 – 8
Output
0 – 8
Output
0 – 10000 or
0 – 30000
Description
CurChgLim defines the maximum rate of change of current for the group of
outputs. This parameter is only used when the output's PinConfig is 4 or 5.
111 is 11.1 mA/ms.
Sets dither frequency when output dither is enabled for the group.
40 is 40 Hz.
Sets the base PWM frequency for the group.
30 is 30 Hz.
Description
Default Output value used when the IO module has not received an output
command within the previous TimeOut_Output.
Output command
Description
Output pin configuration
0: Digital Output, Push/Pull
1: Digital Output, Sourcing
2: Digital Output, Sinking
3: PWM Output, 0 – 10000 [0.01% positive duty]
4: PWM Output, 0 – 30000 [0.1 mA]
5: PWM Output, 0 – 30000 [0.1 mA] Dither Enabled
6: PVE Output, 0 – 10000 [0.01% of PVE Power]
7: HBridge Output, 0 – 10000 [0.01% positive duty]
8: PWM Output 0 – 30000 [0.1 mA] current control bidirectional
Default Output pin configuration used at startup before the master/slave
communication initiates.
0: Digital Output, Push/Pull
1: Digital Output, Sourcing
2: Digital Output, Sinking
3: PWM Output, 0 – 10000 [0.01% positive duty]
4: PWM Output, 0 – 30000 [0.1 mA]
5: PWM Output, 0 – 30000 [0.1 mA] Dither Enabled
6: PVE Output, 0 – 10000 [0.01% of PVE Power]
7: HBridge Output, 0 – 10000 [0.01% positive duty]
8: PWM Output 0 – 30000 [0.1 mA] current control bidirectional
Default Output value used when the I/O module has not received an output
command within the previous TimeOut_Output. The output range depends on
PinConfig.
1000 is 10.00%.
or
1000 is 100.0 mA.
11063395 | AQ00000104en-US0101 | 7
