PLUS+1® Compliant OX024-x10 Function Block
OX024-x10 Function Block
Inputs – DOut Output Status
Signal Type
Pin _Status
Bus
PinStatus U16
Updated BOOL
Inputs – DOut/PVG Pwr Output Status
Signal Type
Pin _Status
Bus
Volt U16
PinStatus U16
Updated BOOL
Inputs – MFOut Output Status
Signal Type
Pin _Status
Bus
FeedBackValue S16
PinStatus U16
Updated BOOL
Outputs – Group
6 | © Danfoss | July 2018
The input status of output pins on connectors and pins C1p06, C1p07, C1p08, and C1p09 is described.
Direction Range
—— ——
Input 0 – 1
Input ——
The input status of output voltage and output status on connectors and pins C1p10 and C1p11 is
described.
Direction Range
—— ——
Input 0 – 36000
Input 0 – 1
Input ——
The input status of multifunction outputs on connectors and pins C1p12, C2p01, C2p02, C2p03, C2p04,
C2p05, C2p06, C2p07, C2p08, and C2p09 is described.
Direction Range
—— ——
Input -32768 –
32767
Input 0 – 2
Input ——
The status for two groups of outputs is described.
A pin group is for C1p12, C2p01, C2p02 and C2p03.
Another pin group is for C2p05, C2p06, C2p07 and C2p08.
Description
Output pin status
0: OK
1: Overload detected. Only detected when DigOut = True.
True when the PinStatus signal is refreshed.
Description
Output pin voltage
100 is 100 mV.
Output pin status
0: OK
1: Overload detected . Only detected when DigOut = True.
True when the Volt and PinStatus signals are refreshed.
Description
Measured current flowing through the output pin.
1000 is 100 mA.
Output pin status.
0: OK.
1: Incorrect pin configuration.
2: Overload detected.
True when the FeedBackValue and PinStatus signals are refreshed.
