User Manual
PLUS+1® Compliant OX024-x10 Function Block
OX024-x10 Function Block
Input Type
Enbl_ResetTest BOOL
BusRecvryTm
U16
DriverRecvryTm
U16
RepTime_Supply U16
RepTime_Status
U16
RepTime_Outputs U16
TimeOut_Outputs
U16
Inputs – Power Supply
Signal Type
C1p02_Pwr
Bus
AnIn U16
Volt U16
Updated BOOL
Inputs – CAN Shield
Signal Type
C1p05_AnIn Bus
AnIn U16
Volt U16
Updated BOOL
© Danfoss | July 2018
Range Description
—— Determines if the I/O module volatile memory is periodically checked to ensure the device has
not lost volatile configuration information due to temporary loss of power.
T: Volatile information is requested from the I/O module and compared every 1 second.
F: Volatile memory is not checked after initialization and temporary loss of power to the I/O
module may go undetected.
BusRecvryTm sets the time the I/O module CAN port waits after going into a "bus off" condition
0–65535
before attempting to go back on the bus.
1000 is 1 ms.
DriverRecvryTm sets the time the I/O module CAN port waits after a CAN error causes the
0–65535
driver to reset before attempting to go back on the bus.
1000 is 1 ms.
0–65535 Determines how often the Power, Sensor Power, and CAN Shield input values are transmitted
from the I/O module.
1000 is 1 ms.
0–65535 Determines how often the Output Status values are transmitted from the I/O module.
1000 is 1 ms.
0–65535 Determines how often the Output values are transmitted to the I/O module.
1000 is 1 ms.
0–65535 Sets the maximum time allowed between commands for each output. If a command is not
received by the I/O module before the TimeOut_Outputs elapses then that output reverts to its
default output value and default pin configuration.
1000 is 1 ms.
The status of power supply input on the connector and pin C1p02 is described.
Direction Range
—— ——
Input 0 – 32767
Input 0 – 36000
Input ——
The status of analog and CAN0 shield inputs on the connector and pin C1p05 is described.
Direction Range
—— ——
Input 0 – 32767
Input 0 – 5250
Input ——
Description
Analog input AD count.
Due to CAN message optimization, this value is approximated by scaling the Volt
signal.
Analog input voltage
100 is 100 mV.
True when the AnIn and Volt signals are refreshed.
Description
Analog input AD count.
Due to CAN message optimization, this value is approximated by scaling the Volt
signal.
Analog input voltage.
100 is 100 mV.
True when the AnIn and Volt signals are refreshed.
11063395 | AQ00000104en-US0101 | 5
