Lt2 Sport; Gps - Bosch IMSA GT Class Scrutineering System Manual

3 | Components
8/38
3.1.3

LT2 Sport

Functional Description: 2 channel lambda sensor controller
Mounting Note:
This device must be fitted in the cockpit on the passenger side foot-well in

an easily accessible IMSA approved location.
Device MUST be installed on anti-vibration mounts (supplied)

Part Number: F02U.V0U.152-01
Electrical Connector Part Number: F02U.V0U.150-01
Temperature Range: -20 to 85 °C
Maximum Current Consumption: 10 amps
Pinout:
3.1.4

GPS

Functional Description: 10 Hz GPS unit
Mounting Note:
This device must be fitted to the top surface of the vehicle roof with

200mm of the roof centerline and with at least 250mm separation from all
other antennas.
Part Number: F02U.V0U.203-01
Pinout:
IMSA Spec GT Scrutineering Logger
Connector F02U.V0U.150-01
Pin Description
1 VS 1
2 VS 2
3 CAN 2 High
4 UN 2
5 IP 2
6 UN 1
7 IP 1
8 RH 2
9 12V+ (KL.30)
10 GND (KL.31)
11 CAN 2 Low
12 VM 2
13 IA 2
14 VM 1
15 IA 1
16 RH 1
Connector ASU603-03SN
Pin Description
1 5V+
2 Gnd
3 RS-232 Tx
