Temp Sensor – M6
Functional Description: Temperature sensor
Use Case:
Intake Temperature:
Manifold/Boost Temperature:
Cockpit Temperature:
Callout: Driver's left bank will be Sensor #1
Part Number: F02U.V02.356-01
Temperature Range: -55 to 300 °C
Thread: M6 x 1
Installation Torque: 8 Nm
Pinout:
Connector
Pin
1
2
3
4
5
IMSA Spec GT Scrutineering Logger
ASL106-05SN
Description
Sensor Gnd
Signal
Bosch Motorsport
