3 | Components
12/38
3.2.1

1 Bar Pressure

Functional Description: Air pressure sensor
Use Case:
Airbox Pressure:

Manifold Pressure:

Restrictor Throat Pressure:

Callout: Driver's left bank will be Sensor #1
Part Number: F02U.V0U.204-01
Pressure Range: 0.1 – 1.15 bar
Pinout:
Connector
Pin
1
2
3
4
5
IMSA Spec GT Scrutineering Logger
ASL106-05SA-HE
Description
5V+
Sensor Gnd
Signal
Bosch Motorsport
