INSTALLATION & APPLICATION GUIDE
Product Description
The Delta GE Lighting Controller is a Native BACnet Application Controller
that communicates on a BACnet MS/TP RS-485 LAN. The controller is
designed for lighting applications and can switch 12 GE lighting relay outputs
per controller. The controller also supports up to 12 Delta BACstats™
connected on its LINKnet sub-network. Lighting strategies are written in
Delta's powerful GCL programming language, rather than residing in fixed
algorithms. Both firmware and controller databases are loadable over the
network.
With its board dimension and capability of switching up to 12 GE lighting
relay zones, the GE Lighting Controller is ideal for mounting in various GE
relay enclosures for both new and retrofit construction projects. The
controller also includes a built-in sequencer for sweeping through and turning
all the lighting relays ON or OFF in a timed sequence. The controller is
completely programmable; GCL programs and BACnet objects can be created
and modified for the specific lighting application.
Contents
MODEL NUMBERS & ACCESSORIES............................................................................ 2
PACKAGE CONTENTS ...................................................................................................... 2
OTHER RELEVANT DOCUMENTS................................................................................. 2
IMPORTANT INFORMATION.......................................................................................... 2
PRODUCT SPECIFICATIONS .......................................................................................... 3
BOARD LAYOUT................................................................................................................. 5
INDICATORS ....................................................................................................................... 6
CONTROLLER ADDRESS DIP SWITCHES ................................................................... 6
JUMPERS .............................................................................................................................. 6
MOUNTING .......................................................................................................................... 8
INPUT & OUTPUT WIRING.............................................................................................. 8
POWER.................................................................................................................................. 8
NETWORK CABLING & REQUIREMENTS .................................................................. 9
NETWORK TOPOLOGY.................................................................................................. 10
NETWORK COMMUNICATIONS SETUP .................................................................... 10
APPLICATION & PROGRAMMING NOTES ............................................................... 11
CAUTIONS & WARNINGS .............................................................................................. 13
COMPLIANCE DECLARATIONS .................................................................................. 13
Document Edition 1.5
Delta Lighting Controller (GE Lighting)
DLC-G1212 (Rev 1.3)
Document Edition 1.5
Page 1 of 15
Advertisement
Table of Contents
Related Manuals for Delta Controls DLC-G1212
Summary of Contents for Delta Controls DLC-G1212
-
Page 1: Table Of Contents
INSTALLATION & APPLICATION GUIDE Delta Lighting Controller (GE Lighting) DLC-G1212 (Rev 1.3) Document Edition 1.5 Product Description The Delta GE Lighting Controller is a Native BACnet Application Controller that communicates on a BACnet MS/TP RS-485 LAN. The controller is designed for lighting applications and can switch 12 GE lighting relay outputs per controller. -
Page 2: Model Numbers & Accessories
V3.21 Firmware & Software CONTROLLER CAPABILITIES & CHARACTERISTICS • The DLC-G1212 was not tested with V3.21 firmware. If loaded with V3.21 it would have similar capabilities and limitations as other DAC products with V3.21 firmware. Page 2 of 15 Document Edition 1.5... -
Page 3: Product Specifications
Delta Controls Product Specifications Power Requirements • 24 VAC • 50 VA (including GE relays) • Class II Ambient Ratings • 32º to 131º F (0º to 55º C) • 10 to 90% RH (non-condensing) Communication Ports NET1 - Main LAN (BACnet MS/TP) •... - Page 4 Delta Lighting Controller (GE Lighting) DLC-G1212 (Rev 1.3) Installation & Application Guide Device Addressing • Set via DIP switch and jumpers, or Software Setup • DIP switch MAC Address Range: 0 to 99 per network segment • Software Address Range: As per the BACnet standard •...
-
Page 5: Board Layout
Delta Controls Board Layout (DLC-G1212) Relay Status Indicator LED Indicators (SCAN & DLC-G1212 PWR) Low Voltage Switch Connection Sweeper Input Port SWITCH 1 24 VAC Power In GE Relay Typical of 12 NET1 (Main MS/TP LAN P t) SWITCH 2... -
Page 6: Indicators
Delta Lighting Controller (GE Lighting) DLC-G1212 (Rev 1.3) Installation & Application Guide Indicators Function Description Scan CPU Scan Indicator Due to memory expansion on this model the LED no longer indicates the CPU scan rate. Power CPU Power Indicator This amber LED turns on to indicate that the controller has 24 VAC applied. - Page 7 Delta Controls +12 DC VOUT POWER SOURCE The binary inputs all have a third terminal connection for supplying power out to those field devices requiring power (i.e., Motion Detectors). This power source out (V ) may be configured for one of two options, which affects all 12 binary outputs.
-
Page 8: Mounting
Delta Lighting Controller (GE Lighting) DLC-G1212 (Rev 1.3) Installation & Application Guide Mounting The GE Lighting Controller is designed for mounting quickly and easily in a number of locations, usually within one of several sizes of GE relay enclosures. Ensure the controller itself is a safe distance away or in some other way protected from relief valves and other water sources. -
Page 9: Network Cabling & Requirements
Delta Controls Network & Cabling Requirements To ensure network stability and reliable communications, particularly at high speeds on a BACnet MS/TP network for a number of devices, it is imperative that you adhere to the following network and cabling requirements:... -
Page 10: Network Topology
Delta Lighting Controller (GE Lighting) DLC-G1212 (Rev 1.3) Installation & Application Guide Network Topology Delta’s GE Lighting Controllers are designed to be installed in a system of V3.22 controllers, and are fully capable as peer-to-peer controllers on a BACnet MS/TP network as Subnet devices, typically with one System device (DCU or otherwise). -
Page 11: Application & Programming Notes
(for occupancy override). LIGHTING CONTROLLERS WITH NO FEEDBACK (RR7 RELAYS) General Electric RR7 relays do not have feedback capability. The Delta Controls GE Lighting Controller, however, defaults to function with feedback. The board will function as though the relays have feedback, until it is programmed to run in a non-feedback condition. - Page 12 GCL. Example You have a Delta Controls GE Lighting Controller, using the General Electric RR7 relays: 1. The Binary Output (BO) of the relays is set to default to ON. Upon reset or start up, the lights controlled by the RR7 relays will all turn ON, while waiting for the GCL program to tell them what to do.
-
Page 13: Cautions & Warnings
Delta Controls Cautions and Warnings The GE Lighting Controller is an Electro-statically sensitive device. Proper ESD protection (ground strap) should be used when installing this product so that damage to the product does WARNING not occur. Compliance Declarations BACnet Testing Labs The Delta Controller Engine (DCE) used in this product is BTL listed (with at least V3.22 firmware). - Page 14 Delta Lighting Controller (GE Lighting) DLC-G1212 (Rev 1.3) Installation & Application Guide UL Compliance Information This product conforms to the following UL requirements: • UL916: Energy Management Equipment. • CAUTION – Risk of Electric Shock – More than one disconnect switch may be required to de-energize the equipment before servicing.
- Page 15 Delta Controls CE - DECLARATION OF CONFORMITY according to ISO/IEC Guide 22 and EN 45014 Manufacturer's Name: Delta Controls Manufacturer's Address: 17850 56 Avenue Surrey, British Columbia Canada V3S 1C7 declares that the product (s): Product Name: GE Lighting Controller...
