Lippert Components Solera Owner's Manual page 7

G
H
M
N O
Callout
G
H
I
J
K
L
M
N
O
Drive Head Gear Kit
P
(Only available
Rev: 08.29.2014
I
P
Part # Description
266156 #6 X ½ ZN Screw (fastener for head covers, 6 per cover)
299630 #8 End Cap Wax Screw (head to rollbar)
118043 Nut ⁄ -18 Nylock ZN ST (head to arm)
266148 Screw ⁄ - 18 X 2 - ¼ (head to arm)
266155 Screw #8-32 x ½ PH PNH MACHG ZN FTHD (back cover to mount)
275071 Rubber Grommet (around manual override on drive head)
2661301 End Cap for power heads (White)
2661302 End Cap for power heads (Black)
299419 Screw - # 8 - 15 X ½ PNH ZN SQ A ST (Endcap to Rollbar)
178231 #10 x ¾ " Hex, Tek Screw (Cord to Rollbar)
Qty.
1
1
1
353964
2
1
as a kit)
1
2
2
J
Part# - Description
266133 - .873" 20 PA 16 DP, D SLOT GEAR
266134 - .442" 20 PA 16 DP, CLR ZN GEAR
266136 - .500" 20 PA 16 DP, CLR ZN GEAR
266142 - Bushing
266143 - Bushing
281828 - Bushing
266137 - E-Clip ½ "
276160 - E-Clip ⁄ "
Page 7
L
K
Solera® Power Awning Owner's Manual
