- Page 1 Infortrend EonServ 7000 Series User Guide Version 1.1...
-
Page 2: Copyright Notice
Infortrend Technology, Inc. Disclaimer Infortrend Technology makes no representations or warranties with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose. Furthermore, Infortrend Technology reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation to notify any person of such revisions or changes. -
Page 3: Legal Information
Standard Warranty Policy available on the Infortrend website: http://www.infortrend.com/global/Support/Warranty Infortrend may from time to time modify, update or upgrade the software, firmware or any accompanying user documentation without any prior notice. Infortrend will provide access to these new software, firmware or documentation releases from certain download sections of our website or through our service partners. -
Page 4: Contact Information
Contact Information Customer Support Contact your system vendor or visit Infortrend’s website http://infortrend.com/global/About/Worldwide for the contact information of support offices worldwide. -
Page 5: About This Guide
This User Guide introduces EonServ 7000 series’ basic hardware/software and recommended procedures to produce a sample for pilot/volume production. If you are already an EonServ 7000 series user, please refer to the hardware and/or software manuals that came with your system for full installation details. ... -
Page 6: Table Of Contents
About This Guide ........................v Revision History ........................v Table of Contents ........................vi 1. Introduction .......................... 1 EonServ 7000 Series Overview .................. 1 EonServ 7000 Series Advantages ................1 EonServ 7000 Series Technology ................2 1.3.1 EonServ Hardware Architecture ................ 2 1.3.2... -
Page 7: Introduction
This design saves space, lowers costs, is green to operate and requires minimum maintenance. In order to meet all your requirements, Infortrend EonServ 7000 series can be turned into the central point of access for all incoming and outgoing data by simply installing the desired operating system. -
Page 8: Eonserv 7000 Series Technology
I/O throughput. 1.3.1 EonServ Hardware Architecture EonServ 7000 series is available in 2U and 3U form factors with various CPU configurations (Intel Xeon E5-2609 v4 and E5-2620 v4). The system supports a maximum of 1024GB DDR4 memory. -
Page 9: Infortrend Raid Platform Virtualization (Irpv)
1.3.3 Intelligent Drive Recovery (IDR) for Better Data Integrity To provide better data integrity, Infortrend EonServ 7000 series’ hard drive error detection and countermeasure mechanism in a RAID6 configuration scans for damaged disk block(s) and attempts to repair it. If the damaged block is beyond... -
Page 10: Sustained Io Throughput
1.4 EonServ 7000 Series Hardware EonServ 7000 series is available in 2U and 3U form factors with various CPU configurations (Intel Xeon E5-2609 v4 and E5-2620 v4). It has two system drive slots (2.5” SATA), 5 PCIe card expansion slots, compatibility with 2.5” SATA SSD, 2.5”... -
Page 11: Controller Module Interfaces
Controller (1) The controller module represents the server component of the system that contains a main circuit board with various output and connections at the rear. Power supply unit (2) The hot-swappable PSUs provide power to the system. 1.4.3 Controller Module Interfaces The controller module is situated next to the two power supply units at the rear of the system. -
Page 12: Initial Setup
The software installation procedure includes setting up the BIOS (for OS installation), OS installation, OS driver installation, SANWatch installation and application software installation. If you are a current EonServ 7000 series user, you can find the supported operating system drivers on the CD that came with your system. -
Page 13: Installing Operating System
Press F2 to access the motherboard BIOS when powering up the system. Go to ‘Boot’ tab and select the desired boot device as Boot Option #1. Save and exit the BIOS. 2.2.2 Installing Operating System EonServ 7000 series drivers support ONLY the following operating systems: Windows 10 ... - Page 14 Install driver for the following devices: SM Bus Controller: Intel C220 chipset driver [SetupChipset.exe] SCSI controller: Infortrend RAID communication driver [ift_raid.sys] Installing Drivers for Linux CentOS 1. Linux CentOS System Driver Installation Use the software update feature of your Linux operating system to install the latest drivers.
-
Page 15: Installing Sanwatch
2.2.4 Installing SANWatch SANWatch is the proprietary software suite that enables you to easily configure and manage Infortrend storage systems. SANWatch can be accessed through a web browser as long as both the computer and the subsystems are online. You are no longer required to install complex desktop application to your local computer: everything is always available over the network. -
Page 16: Appendix
Appendix Dimensions 2U series Dimensions With chassis ears & protrusions Height 88.00mm Width 447.40mm Length 650mm 3U series Dimensions With chassis ears & protrusions Height 130.00mm Width 447.40mm Length 650mm Environment Requirement 5 to 95% (non condensing – operating and non- Humidity operating) Operating: 0º... -
Page 17: Certifications
Certifications UL 60950-1, 2nd Edition BSMI CNS 14336-1: 99 年版 Safety CB IEC 60950-1:2005 (Second Edition) + Am 1:2009 + Am 2:2013 EAC TP TC 004/2011, TP TC 020/2011 CE EN 55032:2012 +AC:2013 / EN61000-3-2:2014 / EN 61000-3-3: 2013 / EN 55024:2010+A1:2015 BSMI (CNS 13438) FCC (FCC Part 15,subpart B ) IEC 60068-2... -
Page 18: Jbod Expansion
JBOD Expansion Setting JBOD IDs Use a small flat blade screwdriver to set the JBOD enclosure ID(s). A different ID number must be allocated for each JBOD. Making Connections 1. Cabling rules: Host system (HBA) to JBOD: SFF-8644/SFF-8644 cable JBOD to JBOD: SFF-8644/SFF-8644 cable 2. -
Page 19: Volume Production
Volume Production When you have completed the basic hardware and software setup, and have your specific application software installed. Then you are ready to test the system with designated task(s) and in desired environment(s) . Once the system has been tested and approved, you may then consider replication in volume for distribution.
