Operator Manual
LS10 and LS12
Levee Seeder
Manufacturing, Inc.
www.greatplainsmfg.com
Printed 5/6/19
Index
EN
117-055M
Advertisement
Table of Contents
Related Manuals for GREAT PLAINS LS10
Summary of Contents for GREAT PLAINS LS10
- Page 1 Table of Contents Index Operator Manual LS10 and LS12 Levee Seeder Manufacturing, Inc. www.greatplainsmfg.com Read this manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! 18173 Illustrations may show optional equipment not supplied with standard unit.
-
Page 2: Machine Identification
Machine Identification Record your machine details in the log below. If you replace this manual, be sure to transfer this information to the new manual. If you or the dealer have added options not originally ordered with the machine, or removed options that were originally ordered, the weights and measurements are no longer accurate for your machine. - Page 3 Great Plains Manufacturing, Inc. provides this publication “as is” without warranty of any kind, either expressed or implied. While every precaution has been taken in the preparation of this manual, Great Plains Manufacturing, Inc. assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein.
- Page 4 LS10 and LS12 Cover Index Table of Contents Great Plains | 117-055M | 5/6/19 Cover Index...
-
Page 5: Safety Information
NOTICE Indicates that equipment or property damage could modification can result in unsafe conditions that lead result if instructions are not followed. to machine damage or personal injury. NOTE: Useful information related to the preceding topic. Great Plains | 117-055M | 5/6/19 Table of Contents Index... -
Page 6: Operation
5. Dispose of unused chemicals and chemical waste as specified by the manufacturer. Observe all the local ordinances and regulations in your area. Operation Noise Hazard Use proper ear protection like headphones or earplugs while working. Great Plains | 117-055M | 5/6/19 Table of Contents Index... -
Page 7: Shutdown And Storage
8. When towing on a trailer, secure implement with tie downs and chains. 9. When towing on a trailer, sudden braking can cause a trailer to swerve and upset. Reduce speed if trailer is not equipped with brakes. Great Plains | 117-055M | 5/6/19 Table of Contents Index... -
Page 8: Safety Decals
Replace all damaged, faded, or being careful not to cause air bubbles under decal. missing decals. Order new decals from your Great Plains dealer. Refer to this section for proper decal placement. When ordering new parts or components, also request corresponding safety decals. -
Page 9: Daytime Reflectors
Warning: Falling Hazard 838-102C WARNING To avoid serious injury or death: Watch your step when climbing ladder or walking on walkboard. 838-102C On both ends of frame, near walkboard; 1 total 18174A Great Plains | 117-055M | 5/6/19 Table of Contents Index... - Page 10 WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov 18174A On front of frame on left side; 1 total Notice: Lubrication Instructions 858-679C 18174A On each end of seeder box; 2 total Great Plains | 117-055M | 5/6/19 Table of Contents Index...
-
Page 11: Intended Usage
Your Great Plains dealer wants you to be satisfied with your new machine. If you do not understand any part of this manual or are otherwise dissatisfied7, Discuss the matter with your dealership service manager. -
Page 12: Preparation And Setup
3/4-inch bolts to clamp seeder to plow frame. 3. Remove ladders from side of seeder. Install ladders to seeder through top set of holes in ladder. 18351 Figure 3 Reposition Ladder for Field Position Great Plains | 117-055M | 5/6/19 Table of Contents Index... -
Page 13: Hydraulic Hose Connections
For future reference, refer to the plastic hose holder to distinguish hoses. 17641 Figure 5 Hydraulic Hose Label Great Plains | 117-055M | 5/6/19 Table of Contents Index... - Page 14 Check hydraulic hoses and fittings for leaks. Repair or replace before going to the field. Check that seed cups and drive are working properly and free from foreign material. Great Plains | 117-055M | 5/6/19 Table of Contents Index...
-
Page 15: Field Operation
Road rules - Comply with all federal, state and local laws when traveling on public roads. Clearance - Remember that the seeder is wider than the tractor. Allow for safe clearance. Great Plains | 117-055M | 5/6/19 Table of Contents Index... - Page 16 Position hoses on seeder frame so hose ends are off the ground. 6. Place the rear parking stand in position as shown. Unhitch the levee plow from the tractor. 18350 Figure 8 Rear Parking Stand Great Plains | 117-055M | 5/6/19 Table of Contents Index...
-
Page 17: Seeding Rate Adjustment
For seed-cup clean out, move the handles to the fourth, wide-open position. Make sure all handles are in the same position before seeding. 16491 Figure 10 Seed-Cup-Door Handle Great Plains | 117-055M | 5/6/19 Table of Contents Index... -
Page 18: Seeding Rate Chart
To adjust the distribution panels: Loosen the bolts in the rear panel slots. 2. Adjust the panel to the desired position and tighten the bolts. 18165 Figure 11 Distribution Panels Great Plains | 117-055M | 5/6/19 Table of Contents Index... -
Page 19: Troubleshooting
“Hydraulic Hose Connections” on page 9. Certain models do not have the same number of cups between each divider Drill box not emptying evenly of bulkhead. The section with more cups will empty sooner. Great Plains | 117-055M | 5/6/19 Table of Contents Index... -
Page 20: Maintenance And Lubrication
5. Inspect hydraulic hoses for cuts, cracks, and aging. Check fittings for evidence of leaks. 6. Replace any worn, damaged, or illegible safety decals. Order new decals from your Great Plains dealer. Refer to “Safety Decals” on page 4. Lubrication... -
Page 21: Removing Seeder From Plow
2. Secure the seeder to the forklift or hoist. 3. Disassemble the flat bars (A) that secure the seeder to the plow frame. 4. Lift the seeder off the plow. 17993 Figure 13 Disassemble Flat Bars Great Plains | 117-055M | 5/6/19 Table of Contents Index... -
Page 22: Specifications And Capacities
12 feet 6 inches Height, Levee Seeder Only 7 feet 2 inches 7 feet 2 inches Box Capacity 24 bushels 29 bushels Tractor Requirements One hydraulic remote One hydraulic remote Great Plains | 117-055M | 5/6/19 Table of Contents Index... -
Page 23: Pre-Delivery Instructions
4. Secure the other bolt with a hose clip (8), lock washer, and nut. 5. Repeat the above steps for the other red light. 71318 Figure 15 Red Light Installation Great Plains | 117-055M | 5/6/19 Table of Contents Index... -
Page 24: Harness Installation
Wire Damage Risk: Make sure all harnesses are secured to machine. To prevent damage to harnesses, do not stretch wires and do not let wires drag on the ground. Great Plains | 117-055M | 5/6/19 Table of Contents Index... -
Page 25: Torque Value Chart
⁄ d. ft-lb = foot pounds 1330 2970 2190 4820 3560 ⁄ 25199m 25199 Torque tolerance + 0%, -15% of torquing values. Unless otherwise specified use torque values listed above. Great Plains | 117-055M | 5/6/19 Table of Contents Index... -
Page 26: Hydraulic Schematics
LS10 and LS12 Table of Contents Index Appendix Hydraulic Schematics 17992 Great Plains | 117-055M | 5/6/19 Table of Contents Index... -
Page 27: Warranty
This Warranty is limited to the replacement of any defective part by Great Plains and the installation by the dealer of any such replacement part. Great Plains reserves the right to inspect any equipment or part which are claimed to have been defective in material or workmanship. - Page 28 LS10 and LS12 Table of Contents Index Appendix Great Plains | 117-055M | 5/6/19 Table of Contents Index...
- Page 29 ........15 seed cup clean out ........13 door ..........13 handle .........13 shaft ........9 seeding rate adjustment .....13 shutdown ..........3 storage ..........3 tire safety ..........2 Great Plains | 117-055M | 5/6/19 Cover Table of Contents...
- Page 30 LS10 and LS12 Cover Table of Contents Index Great Plains | 117-055M | 5/6/19 Cover Table of Contents...
- Page 31 Table of Contents Index Table of Contents Index...
- Page 32 Table of Contents Index Great Plains, Mfg. 1525 E. North St. P.O. Box 5060 Salina, KS 67402...
