14. INSTRUCTION STORAGE AND TRANSPORT
The device should be stored at -10 ° C to + 40 ° C and relative humidity 80% free of corrosive fumes and dusts. Transportation of packaged devices
should be covered means of transport. For transport the packaged unit must be secured against slipping and ensure the correct position.
15. COMPLETE SPECIFICATION
1 Source 90 CUTTER 1 Source 90 CUTTER
2 Holder for plasma cutting the A-81 type Trafimet 2 Holder for plasma cutting the A-81 type Trafimet
3 Ground cable with a clamp 3 Ground cable with a clamp
4 User manual
5 Package 5 Package

16. ELECTRIC SCHEME

90 CUTTER
Source 110 CUTTER
Holder for plasma cutting A-101 type Trafimet
Ground cable with a clamp
User manual
Package
10
110 CUTTER
