3.6.1

Limits after connection to the PC, with the software running

If the crosshead reaches a limit during a test, it will stop then reverse direction for
approximately 5 mm, then stop again. When this happens an onscreen warning message
will be displayed:
Click to acknowledge the warning and use the Jog buttons to move the crosshead so
OK
that you can then check the position of the limit stops and re-set if required.
If a limit stop is reached while pressing one of the Jog buttons on the front panel of the
MultiTest-i a different warning message is displayed.
Clicking will allow you to correct the situation and continue.
OK
Clicking will disconnect the stand and display the following message:
Abort
Click then
OK Exit
8  Mecmesin
to go to the Front Screen, this will reconnect the stand again.
