Summary of Contents for ROBBE CALIMA 2640
- Page 1 PNP-version No.: 2640 ARF-version No.: 2639 Instructions and User Manual www.robbe.com...
- Page 2 In particular, all applicable legal requirements must be observed, which can be found in the roof associations or checked by your specialist dealer or in the Robbe Service or have it replaced. Hidden faults can occur due to the relevant authorities. Failure to comply can result in substantial penalties.
- Page 3 The original declaration of conformity can be found on the Internet at www.robbe. operation.To the extent permitted by law, the obligation to pay damages, irrespective of the legal grounds, shall com, in the detailed product view of the respective device description or on request.
- Page 4 Instructions and User Manual P R E FA C E T E C H N I C A L D ATA Congratulations on your purchase of the new CALIMA. The CALIMA is a allround motorglider with a dynamic flight envelope. It can be flown within in a broad speed range. There are various ways of constructing the model, depen- ding on your preferences.
- Page 5 Instructions and User Manual F U S E L A G E First install the motor on the motor mount by two M3x6 The servos must be placed into the designated wooden Allen screws. Make sure that the screws are tight and frame by already put in neutral position.
- Page 6 Instructions and User Manual The battery will be fixed by a velcro loop on the front The receiver has its place in the rear of the wooden tray battery tray. To avoid slipping the battery, a strip of Velcro and should be fixed by velcro. You can already plug in all should also be glued to the wooden board under the servo plugs according to their assignment.
- Page 7 Instructions and User Manual The linkage of the flaps is realized by a crossover connec- We recommend to glue inner and outer wing part toge- ther by using epoxy. Pay attention to the correct orientati- tion of M2,5 parts through the surface of the wing. The- on during curing process.
- Page 8 Instructions and User Manual Expert tip: The root ribs of the two wing parts have cutouts for MPX plugs. With a little work, you can install the servo or socket cable of the respective wing half using the MPX connector. If the adhesive tape is not sufficient, you can easily install smaller surface connectors in the root ribs.
- Page 9 Instructions and User Manual I N S TA L L AT I O N A N D T U N I N G P R O C E S S Insert both parts of the wing onto the wing connector and Make sure that no wires are stuck between the fuselage connect the plugs of the wing servos.
- Page 10 Instructions and User Manual C O N T R O L T H R O W S Function Normal Speed Thermal Landing Elevator 12mm above/below 1-2mm above 3mm below Rudder 32mm left/right Ailerons 20mm above, 14mm below 1mm above 2mm below 20mm above (or max.) Flaps 2mm above...
- Page 11 Instructions and User Manual F O R Y O U R N O T E S...
- Page 12 4565 Inzersdorf im Kremstal Österreich Telefon: +43(0)7582/81313-0 Mail: info@robbe.com UID Nr.: ATU69266037 „robbe Modellsport“ ist eingetragenes Markenzeichen der Modellbau Lindinger GmbH Irrtum, Druckfehler und technische Änderungen vorbehalten. Copyright 2018 Modellbau Lindinger 2018 Kopie und Nachdruck, auch auszugsweise, nur mit schriftlicher Genehmigung.
