CMOS 16-BIT SINGLE CHIP MICROCONTROLLER
S5U1C17F57T Manual
(Software Evaluation Tool for S1C17F57)
Rev.1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S5U1C17F57T and is the answer not in the manual?

Questions and answers

Related Manuals for Epson S5U1C17F57T

Summary of Contents for Epson S5U1C17F57T

  • Page 1 CMOS 16-BIT SINGLE CHIP MICROCONTROLLER S5U1C17F57T Manual (Software Evaluation Tool for S1C17F57) Rev.1.1...
  • Page 2 Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any liability of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or circuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such as, medical products.
  • Page 3 Configuration of product number Devices 17xxx 00E1 ■Packing specifications 00: Besides tape & reel 0A: TCP BL 2 directions 0B: Tape & reel BACK 0C: TCP BR 2 directions 0D: TCP BT 2 directions 0E: TCP BD 2 directions 0F: Tape & reel FRONT 0G: TCP BT 4 directions...

  • Page 4: Table Of Contents

    RTC Demonstration ......................24 5.2.5 Temperature Measurement Demonstration............... 24 5.2.6 Current Consumption Measurement Demonstration ............25 Appendix A Sample Software File Configuration............26 Appendix B Circuit Diagram and Component List............ 27 Revision History ......................40 Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 5: Overview

    17F57: Software eValuation Tool for S1C17F57) are evaluation and development support boards for the Seiko Epson single-chip microcontroller S1C17F57. The S5U1C17F57T1 is composed of a CPU board and a peripheral board. In the CPU board, an IC socket for the S1C17F57, extension connectors, debug connectors for the S1C17F57 and others are built-in.

  • Page 6: Usage Method

    (3) Insert the coin battery to the battery folder mounted on the peripheral board. (4) Set the power supply switch (SW2) of the peripheral board to the “ON” side. The factory default settings are the above. Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 7 JP18-19 OPEN OPEN OPEN Peripheral JP1-22 JP23 OPEN OPEN BATT JP24-29 ON: Place the jumper switch OPEN: Remove the jumper switch -: Arbitrary Other: Place the jumper switch to the side of this name Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 8: Name And Functions Of Each Part

    RFconvertor switch (JP13) parts area power supply jumper switch (JP17) monitor terminal (TP2) LED (D2) power selection jumper switch (JP14) Figure 2.1 Name of each part for S5U1C17F57T1 CPU board (front side) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 9 Figure 2.2 Name of each part for S5U1C17F57T1 CPU board (reverse side) Note: The No.1 pin position of the CN2-1 (J5) connector is shown above. When connecting the ICDminiVer.2 to this board, confirm the direction of the connector carefully. Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 10 Interface connector CN6 (J13) Reset switch (SW1) Piezo buzzer (BZ1) REGMON monitor Extension connector Tact switches pin (TP5) (CN1-3, J15) (SW3 to 6) Figure 2.3 Name of each part for S5U1C17F57T1 peripheral board (front side) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 11 2. Name and Functions of Each Part Several setting jumper switches Several setting jumper switches Battery folder JP13 JP22 JP21 JP10 JP20 JP19 JP14 JP23 JP17 JP18 JP29 Figure 2.4 Name of each part for S5U1C17F57T1 peripheral board (reverse side) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 12 2. Name and Functions of Each Part Figure 2.5 Connection diagram of EPD module (DM-EPS2) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 13: Functions Of Each Part

    CN3 (J8). Short: Supplies Open: Does no supply. JP18 Connects the S1C17F57 VE1 terminal to Open Short the VE2 terminal. JP19 Connects the S1C17F57 VE2 terminal to Open Short the V terminal. Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 14: Functions Of Each Component

    System reset Monitor pin TP1(VPP) VPP (USB VBUS boost) power supply monitor pin Monitor terminal TP2(V power supply monitor through-hole Monitor terminal TP3,TP4 Serial interface signal monitor through-hole Capacitor Reference capacitor (DC/AC bias, channel 0) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 15 P00 (REGMON) monitor pin Buzzer Piezo buzzer Battery folder For the coin battery (When the coin battery is inserted, do not supply a power from the CN3 (external power supply connector) of the CPU board.) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 16: Block Diagram

    CB1-4 CD1-2 S1C17F57 Crystal OSC4 (IC socket) 4.000MHz OSC3 OSC2 Crystal OSC1 32768Hz CPU Board CN2-2 CN2-1 (S5U1C17F57T2) Tact Buzzer switch x 4 ICDmini Ver.2 PC(GNU17 v2.0.0 or over) Figure 3.1 S5U1C17F57T1 block diagram Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 17: Connectors

    ESEG42 EPD segment output ESEG59 EPD segment output ESEG41 EPD segment output ESEG58 EPD segment output ESEG40 EPD segment output ESEG57 EPD segment output Power supply (-) ESEG56 EPD segment output Power supply (-) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 18 P23/SCLM/RFIN0 supply Unconnected Power supply (-) TEST0 Input for testing P22/SDAM/REF0 #RESET Initial reset output Power supply (-) Power supply (-) P21/SCLS/SENA0/#BZ DCLK DCLK/P34 Power supply (-) Power supply (-) Power supply (-) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 19: Debug Interface Connectors (Cn2-1 To Cn2-2)

    Function Power supply (+) Power supply (GND) 4.1.4 USB Connector (CN4) Table 4.8 Pin assignment table for CPU board USB connector (CN4) Terminal name Function VBUS Power supply (+5V) Unconnected USBGND Power supply (GND) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 20: Peripheral Board Connectors

    Function name name SPI interface control data XRES Unconnected output SPI interface control data Power supply (+) output Power supply (-) Unconnected SPI interface control Unconnected clock input SPI interface control chip Unconnected select Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 21: Epd Panel Interface Connector (Cn7-1)

    ESEG9(MCU) CN11 ESEG55(MCU) CN56 ESEG10(MCU) CN10 ESEG56(MCU) CN55 ESEG11(MCU) ESEG57(MCU) CN54 ESEG12(MCU) ESEG58(MCU) CN53 ESEG13(MCU) ESEG59(MCU) CN52 ESEG14(MCU) ESEG60(MCU) CN51 ESEG15(MCU) ESEG61(MCU) CN50 ESEG16(MCU) ESEG62(MCU) CN49 ESEG17(MCU) ESEG63(MCU) CN48 ESEG18(MCU) EBP1(MCU) CN47 ESEG19(MCU) ETP1(MCU) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 22: Epd Panel Interface Connector (Cn7-2)

    CN15 CN60 ESEG30(MCU) CN14 CN59 ESEG31(MCU) CN13 CN58 ESEG32(MCU) CN12 CN57 ESEG33(MCU) CN11 CN56 ESEG34(MCU) CN10 CN55 ESEG35(MCU) CN54 ESEG36(MCU) CN53 ESEG37(MCU) CN52 ESEG38(MCU) CN51 ESEG39(MCU) CN50 ESEG40(MCU) CN49 ESEG41(MCU) CN48 ESEG42(MCU) CN47 ESEG43(MCU) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 23: Epd Panel Interface Connector Pads (Cn8-1 To 3)

    ESEG7(MCU) CN11 ESEG55(MCU) CN58 ESEG8(MCU) CN10 ESEG56(MCU) CN57 ESEG9(MCU) ESEG57(MCU) CN56 ESEG10(MCU) ESEG58(MCU) CN55 ESEG11(MCU) ESEG59(MCU) CN54 ESEG12(MCU) ESEG60(MCU) CN53 ESEG13(MCU) ESEG61(MCU) CN52 ESEG14(MCU) ESEG62(MCU) CN51 ESEG15(MCU) ESEG63(MCU) CN50 ESEG16(MCU) EBP1(MCU) CN49 ESEG17(MCU) ETP1(MCU) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 24: Epd Panel Interface Connector Pads (Cn9-1)

    ESEG5(MCU) CN11 ESEG55(MCU) CN60 ESEG6(MCU) CN10 ESEG56(MCU) CN59 ESEG7(MCU) ESEG57(MCU) CN58 ESEG8(MCU) ESEG58(MCU) CN57 ESEG9(MCU) ESEG59(MCU) CN56 ESEG10(MCU) ESEG60(MCU) CN55 ESEG11(MCU) ESEG61(MCU) CN54 ESEG12(MCU) ESEG62(MCU) CN53 ESEG13(MCU) ESEG63(MCU) CN52 ESEG14(MCU) EBP1(MCU) CN51 ESEG15(MCU) ETP1(MCU) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 25: Epd Panel Interface Connector Pads (Cn9-2)

    ESEG7(MCU) CN11 ESEG55(MCU) CN58 ESEG8(MCU) CN10 ESEG56(MCU) CN57 ESEG9(MCU) ESEG57(MCU) CN56 ESEG10(MCU) ESEG58(MCU) CN55 ESEG11(MCU) ESEG59(MCU) CN54 ESEG12(MCU) ESEG60(MCU) CN53 ESEG13(MCU) ESEG61(MCU) CN52 ESEG14(MCU) ESEG62(MCU) CN51 ESEG15(MCU) ESEG63(MCU) CN50 ESEG16(MCU) EBP1(MCU) CN49 ESEG17(MCU) ETP1(MCU) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 26: Epd Module Interface Connector Pad (Cn10)

    SPI interface control Initialization control XRES chip select output output Flash memory serial MFDI Power supply (+) control data input Flash memory Flash memory serial MFDO programming power control data output supply Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 27: Sample Software Manipulation

    5. Sample Software Manipulation Sample Software Manipulation The S5U1C17F57T is shipped with the demonstration software that is programmed to the S1C17F57 mounted in this board. The manipulation method is described here. By manipulating the demonstration software, various functions such as temperature measurement, timer, switch input, EPD display and current consumption measurement are confirmed.

  • Page 28: Epd Drive Waveform Selection

    When the SW4 is pressed while the RTC demonstration software is running, the temperature is displayed. When the SW3 is pressed while the temperature measurement, [time: minute, second, (mark of the sun)] is displayed. Figure 5.2 Display example of temperature measurement Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 29: Current Consumption Measurement Demonstration

    Press the reset key while holding down the SW5 and SW6. Press the reset key while holding down the SW3, SW5 and SW6. *1 4MHz *2 2MHz *3 TCLK:256Hz(OSC1/256), Doubler=On, DCLK=32768Hz(OSC1/1), Booster=On, BCLK=16384Hz(OSC1/2), VEPD=15V, VE1=1.76V Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 30: Appendix A Sample Software File Configuration

    ├─ t16a2.h t16a2.c │ ├─ epd.h epd.c │ ├─ ext_epd.h ext_epd.c │ └─ tem.h tem.c │ └─ [common] Application relating header file ├─ clg_api.h ├─ port_api.h … ├─ t16a2_api.h ├─ epd_api.h ├─ ext_epd_api.h └─ tem_api.h Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 31: Appendix B Circuit Diagram And Component List

    Appendix B Circuit Diagram and Component List Appendix B Circuit Diagram and Component List Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 32 Appendix B Circuit Diagram and Component List Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 33 Appendix B Circuit Diagram and Component List Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 34 Appendix B Circuit Diagram and Component List Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 35 Appendix B Circuit Diagram and Component List Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 36 Appendix B Circuit Diagram and Component List Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 37 Appendix B Circuit Diagram and Component List Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 38 HWP-2P 2pin Mac-Eight JP13,JP17, Co.,Ltd. JP18,JP19 JP4,JP5,JP6, SOLDER_ PAT only JP7,JP8,JP9, JUMPER JP10,JP11, JP15,JP16 JP14,JP12 Checkpin HWP-3P 3pin Mac-Eight Co.,Ltd. J1,J2,J3,J4 Connector HIF3FB-40DA-2.54DSA 40pin, HIROSE CN1-1 to 4 (71) 2.54mm, ELECTRIC Female CO., LTD. Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 39 RK73H2ATTD1002F 10kΩ, 2125 Corporation Tact switch SKRAAKE010 Surface ALPS mount ELECTRIC CO., LTD. Check pin LC-22-G-RED Red, Mac-Eight φ1.0mm Co.,Ltd. PAT only PAT only PAT only IC socket IC51-1284-1788 QFP15-128 Yamaichi Electronics Co., Ltd. Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 40 CP2102 QFN-28 Silicon Laboratories Inc. Crystal MA-406(CL=16pF) 4.000MHz EPSON oscillator TOYOCOM CORPORATION Crystal MC-146(CL=12.5pF) 32768Hz EPSON oscillator TOYOCOM CORPORATION Resistor RK73Z1ETTP(1005) 0Ω Corporation *1: The components and accessories are subject to change without notice. Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 41 PAT only(04 6286 96pin, KYOCERA CN9-2 096 102 883+) zigzag, ELCO (CN-EXT_C04) 0.4mm Corporation Connector PAT only 100pin, DDK Ltd. CN9-1 (FFX2-100A-R11AL) 0.2mm (CN-EXT_C02) Connector PAT only CN8-1 (CN-EXT_S03) Connector PAT only CN8-2 (CN-EXT_S04) Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 42 PAT only VDD_PER PAT only GND_BAT PAT only VPP_PER PAT only No mount TQFP12-64 SN74LVC1G08DCK Texas (SC-70)-DCK Instruments Checkpin LC-22-G-RED Red, Mac-Eight φ1.0mm Co.,Ltd. *1: The components and accessories are subject to change without notice. Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
  • Page 43 ASB-309.5E component L=9.5mm Co., Ltd. Mounted Spacer clamping FB-0305N M=3, L=5mm Wilco. component screw Mounted M=3, HIROSUGI-KEIKI Spacer ASB-312E component L=12mm Co., Ltd. *1: The components and accessories are subject to change without notice. Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)

  • Page 44: Revision History

    Revision History Revision History Attachment-1 Code No. Page Contents 412124900 Newly established 1,6,10,1 The description concerning S1D14F51 was deleted. 1,12,16, 18,19,20 ,21,38 Back “NOTICE “was changed. cover Seiko Epson Corporation S5U1C17F57T Manual (Rev.1.1)
