Formax FD 574 Operator's Manual

Tabletop cut-sheet cutter
Hide thumbs Also See for FD 574:

Advertisement

Quick Links

FD 574
Tabletop Cut-Sheet Cutter
OPERATOR MANUAL
5/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FD 574 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Formax FD 574

  • Page 1 FD 574 Tabletop Cut-Sheet Cutter OPERATOR MANUAL 5/2018...
  • Page 3 Introduction Thank you for purchasing the Cut Sheet Cutter FD 574. To ensure safe and effi cient prolonged use of this machine, read and thoroughly understand this manual before using the machine. After using this manual, be sure to keep it in a handy place to reference.
  • Page 4: Notes On Safety (Please Read And Observe)

    Notes on Safety (Please Read and Observe) Safety Precautions Various symbols and pictures are used in this manual and on the labels affi xed to the machine. These symbols and pictures provide warnings and instructions to prevent danger to you or other personnel, and to prevent damage to offi...
  • Page 5 ● Caution for Grounding WARNING ● Use only the power cord that is provided among the accessories. Insert the power cord plug fi rmly into the socket, so that proper electrical contact is effected. Use of any other power cord could result in imperfect grounding. If grounding is imperfect and electrical leakage occurs, fi...
  • Page 6 ● Prohibition of Disassembly or Modifi cation WARNING ● Do not modify the machine. →Doing so may result in fi re or electric shock. ● Do not remove the rear lid, cabinet, or covers from the machine. → The inside of the machine contains high-voltage parts, which may cause electric shock.
  • Page 7 ● Caution for Cleaning CAUTION ● Before cleaning the machine, turn off the power switch and unplug the power cord. →If the machine is activated accidentally, injury may result. ● Do not use fl ammable sprays or solvents inside or near the machine. →Gas may accumulate inside the machine causing a fi...
  • Page 8: Locations Of Warning Labels

    Locations of Warning Labels Keep the WARNING and CAUTION labels clean at all times. If labels become damaged or come off, contact our service personnel. <Paper infeed side> U80001 U80002A...
  • Page 9 <Paper ejection side> U80003 <Paper ejection side (without rear cover)> U80004 Part No. Name Q'ty 1. J4-Y4040 CAUTION LABEL 2. M7-T3030 WARNING LABEL 3. K9-T1390 WARNING LABEL 4. L8-T1070 WARNING LABEL...
  • Page 10 <Options> Perforator (standard/micro) unit Center slitter unit Open the top cover. Upper plate (front) U82313 Paper infeed side Part No. Name Q'ty 1. J4-Y4050 WARNING LABEL 2. L8-T1070 WARNING LABEL viii...
  • Page 11: Table Of Contents

    Contents ................Introduction ........Notes on Safety (Please Read and Observe) .............. Safety Precautions ..........Locations of Warning Labels Before Using This Machine Chapter 1 ..........Part Names and Their Functions ..........Appearance (Paper Infeed Side) .......... Appearance (Paper Ejection Side) ..............
  • Page 12 Contents Chapter 4 Using Useful Functions ..............Function Settings ............ 1. Double Feed Detection ............2. Slitter/Perforation ............. 3. Preset Counter ................ 4. Speed ............5. Downstream Unit ........... 6. Cut Position Adjustment ..............7. JOB Display ............. 8. Auto Power Off ................
  • Page 13 Chapter Before Using This Machine This chapter contains essential information such as the names of the machine parts, the names and functions of keys on the control panel, and the acceptable paper etc. Please be sure to read this chapter carefully before using the machine.
  • Page 14: Part Names And Their Functions

    Part Names and Their Functions Appearance (Paper Infeed Side) U80002 Name Function Feed tray Load paper on this tray. Open this tray when loading the paper. Close the tray when not Support tray used. Set the position of these guides according to the width of the Paper feed guides paper.
  • Page 15: Appearance (Paper Ejection Side)

    Part Names and Their Functions Appearance (Paper Ejection Side) U80004B Name Function Stacker Receives the ejected paper. Ejection guide Set these guides according to the width of the paper. Paper stopper Set this stopper according to the length of the paper. Open this cover to remove any paper jammed in the cutter unit.
  • Page 16: Control Panel

    Part Names and Their Functions Control Panel TEST START STOP MENU CLEAR RETURN U80005E Name Function LCD panel Displays various messages. TEST key Performs proof feed. (one sheet) JOG REVERSE The paper is fed backward slowly while this key is pressed. JOG FORWARD The paper is fed forward slowly while this key is pressed.
  • Page 17: Lcd Panel

    Part Names and Their Functions LCD Panel •Standby Screen <Display without Preset Counter> <Display with Preset Counter> 3 pcs 3 pcs ****** ****** 1234shts 123/456shts MENU MENU CLEAR CLEAR RETUR RETUR U80000mE U80000mE Name Function Counter Displays the current number of sheets that have been processed. Processing mode Displays the current processing mode.
  • Page 18: Turning Power On/Off

    Turning Power ON/OFF Turing Power ON Insert the female plug of the power cord supplied into the ‘inlet’ on the paper infeed side of the machine. Female plug Inlet of power cord U80021 Insert the male plug of the power cord into the out- let (three-slot).
  • Page 19: Turning Power Off

    Turning Power ON/OFF Turning Power OFF Press the ‘ O ’ side on the power switch to turn the power OFF. The power to the machine turns off and the panel display disappears. U80033...
  • Page 20: Acceptable Paper

    Acceptable Paper Paper size Length : 110 - 420 mm (4.334 - 17 inches) Width : 106 - 364 mm (4.1764 - 14.3416 inches) Paper weight 58-157 gsm (50 - 135 kg) Feed tray capacity 500 sheets (paper weight : 55 kg/64 gsm, bond paper) Capacity varies depending on paper alignment or curl.
  • Page 21: Basic Operation

    Chapter Basic Operation This chapter describes basic operations from preparation before use until taking out the cut paper............Procedure for Using the Machine ..............About Display Screens ................. Standby Screen ..............Menu Selection Screen .............. Function Setting Screen ..............Preparation Before Use ..............
  • Page 22: Procedure For Using The Machine

    Procedure for Using the Machine Preparation Before Use....Setting the Support Tray (→ P.13) Loading the Paper (→ P.13) Adjusting Feed Pressure according to Paper Thickness (→ P.15) Aligning the Paper Retaining Plates (→ P.16) Turning Power ON......Turning Power ON/OFF (→ P.6) (When you install the options, perform the setting.) Selecting Direct Processing (→...
  • Page 23: About Display Screens

    About Display Screens Standby Screen ● When the power is turned ON, the LCD panel displays the screen that appeared when the power 3 pcs was last turned ON. 1234shts ****** MENU CLEAR RETUR U80000mE Selecting Direct Processing ● Each time you press the MENU LEFT key or 3 pcs MENU RIGHT key, the LCD panel sequentially...
  • Page 24: Function Setting Screen

    About Display Screens Function Setting Screen When the menu selection screen is displayed, select ‘Func. Set’ and press the MENU/OK key. The function ► Function(1/9) setting screen appears. 1. DBL FD detect. Each time you press the MENU RIGHT key, the MENU following function settings appear in order.
  • Page 25: Preparation Before Use

    Preparation Before Use The following describes preparation before use. Setting the Support Tray Open the support tray. U80023 Loading the Paper Lower the paper set lever. Loosen the fi xing screws of the paper feed guides to move the paper feed guides to each side. Paper set lever Paper feed guides U80025...
  • Page 26 Preparation Before Use Load the paper on the feed tray. Position the paper feed guides according to the paper width and secure with the fi xing screws. Position the paper approximately in the middle of the feed tray. Otherwise, the paper may not be fed in a straight line, resulting in paper feed errors or jams.
  • Page 27: Adjusting Feed Pressure According To Paper Thickness

    Preparation Before Use Adjusting Feed Pressure according to Paper Thickness Set the feed pressure lever according to the paper thickness. The ‘NORMAL PAPER’ position is the reference position. HEAVY PAPER NORMAL ● For thin paper: Set the feed pressure lever to the PAPER ‘LIGHT PAPER’...
  • Page 28: Aligning The Paper Retaining Plates

    Preparation Before Use Aligning the Paper Retaining Plates Open the top cover. Top cover U80028 Loosen the four thumbscrews and move the paper Thumbscrews retaining plates as shown below. Paper retaining plates ● Two outer plates: Move each of them to each end of the paper.
  • Page 29 Preparation Before Use Close the top cover. Top cover 上カバー U80031...
  • Page 30: Basic Operation

    Basic Operation Menu Selection ● Direct Processing: → P.18 ● Standard JOB: → P.19 ● Custom JOB: → P.24 ● Auto Cut: → P.31 ● Function Settings: → P.36 Direct Processing Processing modes previously used are displayed on the standby screen. You can use the displayed processing mode to easily perform processing without a new setting.
  • Page 31: Standard Job

    Basic Operation Standard JOB You can select paper size and the number of pieces from the pre-programmed data. Make sure that the LCD panel displays the standby screen. 3 pcs (Right fi gure: Standby screen 1234shts ****** The preset counter is not set.) MENU Press the MENU/OK key to display the menu selection screen.
  • Page 32 Basic Operation Select paper size. P a p e r s i z e ? ► You can select from among A3, A4, A5, B4, B5, 14 inches, 11 inches, and 8.5 inches. MENU Press the MENU LEFT key or MENU CLEAR RIGHT key to select paper size and press the...
  • Page 33 Basic Operation Select the number of pieces to be cut. C u t i n t o ? ● Settable number of pieces 3pcs No Cut A3 : 2 to 7 pcs. MENU A4 : 2 to 5 pcs. CLEAR A4R : 2 to 3 pcs.
  • Page 34: Taking Out The Cut Paper

    Basic Operation 2. Press the START key to start operation. All the papers loaded on the feed tray are processed. To stop the operation, press the STOP key. When you want to specify the number of sheets, refer to ‘3. Preset Counter’ in chapter 4. Taking Out the Cut Paper Take out the cut papers from the stacker.
  • Page 35: Menu Selection

    Chapter Menu Selection This chapter desicribes the operation menu other than Standard JOB described in chapter 2.................. Custom JOB ............Memory No. and JOB Details ..................Auto Cut...
  • Page 36: Custom Job

    Custom JOB To cut paper in custom size other than the Standard JOB, save the paper size and cut size that you want to set, and retrieve the memory No. When the standby screen is displayed, press the MENU/OK key to display the menu selection Standard Custom screen.
  • Page 37 Custom JOB Retrieving Retrieve JOB 1. Each time you press the MENU LEFT key M00: 3: 297.0mm MENU RIGHT key, memory no., number of pieces, and paper length sequentially appear. MENU Display the memory no. that you want to select and press the MENU/OK key.
  • Page 38 Custom JOB 3. When any data is already saved, ‘M** Saved’ appears. Select JOB No. Saved MENU CLEAR RETUR U80000dE When you select a memory no. that is already saved, ‘Saved JOB’ appears. Saved JOB ► O v e r w r i t e Cancel To overwrite the data, press the MENU LEFT key or...
  • Page 39 Custom JOB You can set cut position in the range of ‘0.1 to (paper length-0.1 mm)’ except for Paper feed direction the following ranges. 17.1mm from the leading Unavailable ranges: edge This area is not available. • 17.1 to 54.9 mm from the leading edge of 54.9mm from the leading the paper...
  • Page 40 Custom JOB 7. Set the third and its following cut position in the same way as step 6. Cut No.* length? After each setting is complete, press the MENU/ ► 0.0 mm OK key. MENU CLEAR After the last cut position is set, enter ‘0.0 mm’ RETUR and press the MENU/OK key.
  • Page 41 Custom JOB Deleting Select JOB No. 1. Press the MENU LEFT key or MENU Saved RIGHT key to select the memory no. that you want to delete. MENU Then press the MENU/OK key. CLEAR RETUR U80000dE If no data is saved, ‘Unsaved’ appears. Select JOB No.
  • Page 42: Memory No. And Job Details

    Custom JOB Memory No. and JOB Details You can use the form below for your convenience. Cut No.1 Cut No.2 Cut No.3 Cut No.4 Cut No.5 Cut No.6 Cut No.7 Paper Length Memory No.
  • Page 43: Auto Cut

    Auto Cut When a single sheet of paper is fed, the machine automatically measures the paper length and performs cut operation by specifying the number of cuts. When the LCD panel displays the standby screen, press the MENU/OK key to display the menu Standard Custom selection screen.
  • Page 44 Auto Cut ‘Measuring’ appears. Measuring A single sheet of paper is fed into the machine and P l e a s e w a i t paper length is measured, and the paper is ejected into the stacker without cutting. MENU CLEAR RETUR...
  • Page 45 Auto Cut Press the MENU LEFT key or MENU RIGHT key to select ‘Start’ or ‘Save’ and press the MENU/ S t a r t o p e r a t i o n ? OK key. ► Start Save If you select ‘Start’, go to step .
  • Page 46 Auto Cut 2. When you select saved memory no., the confi rming display whether to overwrite the data Saved JOB appears. ► O v e r w r i t e Cancel Press the MENU LEFT key or MENU MENU RIGHT key to select ‘Overwrite’...
  • Page 47 Chapter Using Useful Functions This chapter describes operations using useful functions. You can use useful functions depending on your needs................Function Settings ............1. Double Feed Detection ..............2. Slitter/Perforation ..............3. Preset Counter ................4. Speed ..............5. Downstream Unit ............
  • Page 48 Function Settings The following describes how to select function. When the standby screen is displayed, press the MENU/OK key. 3 pcs ****** 1234shts MENU CLEAR RETUR U80000mE The menu selection screen appears. Press the MENU LEFT key or MENU Standard Custom RIGHT key to select ‘Func.
  • Page 49: Function Settings

    Function Settings The following describes how to set each function. 1. Double Feed Detection This sets double feed detection according to the paper that you are using. Default setting is ‘Mid’ (middle level). Select ‘1. DBL FD detect.’ on the function setting screen and press the MENU/OK key.
  • Page 50: Slitter/Perforation

    Function Settings Function Settings 2. Slitter/Perforation This function is set when a center slitter unit (optional) or perforator (standard/micro) unit (optional) is connected. When ‘ON’ is selected: If you press the TEST key once, the paper stops in front of the slitter and you can check slit position by pressing JOG REVERSE key or JOG FORWARD key.
  • Page 51: Preset Counter

    Function Settings 3. Preset Counter This function stops processing by the specifi ed number of sheets. When you want to perform continuous processing, set the counter to ‘0’. Default setting is ‘0’. Select ‘3. Preset counter’ on the function setting screen and press the MENU/OK key.
  • Page 52: Speed

    Function Settings Function Settings 4. Speed This function sets processing speed of the machine. Default setting is ‘Mid’ (middle speed). Select ‘4. Speed’ on the function setting screen and press the MENU/OK key. ► Function(4/9) 4.Speed If you press the CLEAR/RETURN key, the display returns to the menu selection screen.
  • Page 53: Downstream Unit

    Function Settings 5. Downstream Unit This function is set when an optional straight conveyor is connected. The connected optional unit is automatically recognized. However, you can change the setting manually. • If the power to the machine is on when the optional unit is connected, the optional unit is not recognized automatically.
  • Page 54: Cut Position Adjustment

    Function Settings Function Settings 6. Cut Position Adjustment This function shifts cut position for value set on Cut Position Adjustment (Cut pos. adj.) screen. + (plus) setting shifts cut position backward for value from the paper leading edge. - (minus) setting shifts cut position forward for value from the paper leading edge. Default setting is ‘0.0 mm’.
  • Page 55: Job Display

    Function Settings 7. JOB Display Setting the display of processing mode (JOB details) that you do not use to ‘OFF’ (not displayed) enables you to search processing mode easier. However, you cannot set the display of saved Custom JOB to ‘OFF’. Even if you set the display to ‘OFF’, if you select and perform the processing mode (JOB details) in Standard JOB setting, the display setting is changed to ‘ON’...
  • Page 56 Function Settings Function Settings Press the MENU LEFT key or MENU RIGHT key to select ‘ON’ or ‘OFF’ and press the A4 2 pcs MENU/OK key. ► (Right fi gure: ‘OFF’ is selected.) MENU If you press the CLEAR/RETURN key, the display returns to the function setting screen in step CLEAR RETUR...
  • Page 57: Auto Power Off

    Function Settings 8. Auto Power Off This function automatically turns off the power to the machine if you do not touch the control panel for a certain period of time. Default setting is ‘15 minutes’. Select ‘8. Auto power off’ on the function setting screen and press the MENU/OK key.
  • Page 58: Exit

    Function Settings Function Settings 9. Exit This fi nishes function setting. Select ‘9. Exit’ on the function setting screen and press the MENU/OK key. ► Function(9/9) 9 . E x i t The display returns to the menu selection screen. MENU CLEAR RETUR...
  • Page 59: Optional Equipment

    Chapter Optional Equipment This chapter describes operations with an optional center slitter unit and perforator (standard/micro) unit installed............. How to Use Center Slitter Unit ............... Using as a Slitter ............Using as a Gutter Defl ector .......... How to Use Perforator (Standard/Micro) Unit...
  • Page 60: How To Use Center Slitter Unit

    How to Use Center Slitter Unit WARNING • Take extreme care to keep your hands off the upper and lower blades of the center slitter unit . → These exposed blades can injure you. Using as a Slitter Open the top cover and loosen the two hexagon Top cover socket set screws in the collars with the hexagon wrench supplied.
  • Page 61: Using As A Gutter Defl Ector

    How to Use Center Slitter Unit Press the TEST key again. Proof feed (one sheet) is performed. Check whether it is correctly cut. TEST A4 3 pcs 1234shts MENU CLEAR RETURN U80202Ie Using as a Gutter Defl ector The following describes how to use the center slitter Paper retaining plates as a gutter defl...
  • Page 62 How to Use Center Slitter Unit Refer to ‘2. Slitter/Perforation’ in chapter 4 to set the ‘SLT/PFR’ to ‘ON’. Close the top cover and select ‘No Cut’ on the Upper blade unit processing menu screen, and then press the TEST R guide unit key.
  • Page 63: How To Use Perforator (Standard/Micro) Unit

    How to Use Perforator (Standard/Micro) Unit WARNING • Take extreme care to keep your hands off the upper blade of the perforator (standard/micro) unit . → This exposed blade can injure you. Open the top cover and loosen the hexagon socket Top cover set screws on the cylinder with the hexagon wrench supplied.
  • Page 64 How to Use Perforator (Standard/Micro) Unit Refer to ‘2. Slitter/Perforation’ in chapter 4 to set the ‘SLT/PFR’ to ‘ON’. Close the top cover and select processing mode, and then press the TEST key. The paper is fed forward to the position of the upper guide unit. Use the JOG FORWARD key and REVERSE key to check the cut position.
  • Page 65: Troubleshooting

    Chapter Troubleshooting This chapter describes what to do when an error has occurred and how to deal with paper jams and error messages................If Trouble Occurs ..............When Messages Appear ............Corrective Action for Paper Jams ......How to Remove Jammed Paper from Infeed Area ....
  • Page 66: If Trouble Occurs

    If Trouble Occurs Failures may result from various causes. Listed below are major symptoms along with corresponding check points and corrective actions. See the reference pages for more information on the respective corrective actions. Contact service personnel if any symptom is not cleared by the corrective action.
  • Page 67: When Messages Appear

    When Messages Appear Error messages appear on the LCD panel when the machine does not operate even when the START key is pressed. Take corrective actions below and then press the STOP key. The standby screen will appear and the machine will be ready for operation. Error Message Status and Solution Status:...
  • Page 68 When Messages Appear Error Message Status and Solution Status: The cutter is locked due to a paper jam. E1:CTR MTR Locked Solution: Solution: Remove the jammed paper in the cutter area and then press the STOP key or CLEAR/RETURN key to clear the Check cutter area.
  • Page 69: Corrective Action For Paper Jams

    Corrective Action for Paper Jams How to Remove Jammed Paper from Infeed Area WARNING • Make sure that the power plug is disconnected from the outlet before putting your hand close to any moving part to remove jammed paper. Turn off the power switch and remove the power plug from the outlet.
  • Page 70: How To Remove Jammed Paper From Center Area Or Cutter Unit

    Corrective Action for Paper Jams How to Remove Jammed Paper from Center Area or Cutter Unit WARNING • Make sure that the power plug is disconnected from the outlet before putting your hands close to any moving part to remove jammed paper. •...
  • Page 71 Corrective Action for Paper Jams 4. If paper is jammed in the cutter unit, remove Thumbscrews the two thumbscrews on the rear cover to remove the cover. Rear cover U80255 5. Remove the jammed paper. Cutter unit If paper is jammed in the cutter unit, use the tweezers supplied to remove the paper.
  • Page 73: Daily Maintenance

    Chapter Daily Maintenance This chapter describes daily maintenance of the machine................Daily Maintenance...
  • Page 74: Daily Maintenance

    Daily Maintenance Clean the machine periodically to maintain its performance. WARNING ● Before cleaning, be sure to turn the power off, wait until the machine cools off and unplug the power cord. Otherwise, fi re or electric shock may occur. ●...
  • Page 75: Specifi Cations

    Chapter Specifi cations This chapter describes the machine specifi cations................. Specifi cations...
  • Page 76: Specifi Cations

    Specifi cations Cut Sheet Cutter FD 574 Model name Type Tabletop type cut sheet cutter Paper size Length: 110 - 420 mm (4.334 - 17 inches) Width: 106 - 364 mm (4.1764 - 14.3416 inches) Paper weight 58 - 157 gsm (50 - 135 kg), 1 part/single sheet Minimum cut size 55 mm (2.166 inches)
  • Page 77 Specifi cations Cut Sheet Cutter FD 574 Model name Other features Interlock safety cover (top cover / rear cover) Sheet counter (0 - 9999 sheets) Cutter counter (0 - 9999 cuts) Preset counter (0 - 999 sheets) JOB display (ON/OFF) Slitter checking mode Auto select of fi...
