Formax Cut-True 29H Operator's Manual

Hydraulic guillotine cutter
Hide thumbs Also See for Cut-True 29H:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operator's Manual
Cut-True 29H
Hydraulic Guillotine Cutter
MyBinding.com
5500 NE Moore Court
Hillsboro, OR 97124
Toll Free: 1-800-944-4573
Local: 503-640-5920
11/2016
OPERATOR MANUAL
First Edition

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cut-True 29H and is the answer not in the manual?

Questions and answers

Related Manuals for Formax Cut-True 29H

Summary of Contents for Formax Cut-True 29H

  • Page 1 Cut-True 29H Hydraulic Guillotine Cutter MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 OPERATOR MANUAL Toll Free: 1-800-944-4573 Local: 503-640-5920 First Edition 11/2016...

  • Page 2: Unpacking And Assembly

    1. UNPACKING AND ASSEMBLY The Cut-True 29H is is shipped partially assembled and ready to use (Figure 1a). The cutter's optional side-tables will need to be installed on-site, according to Figure 1b. Figure 1a. Cut-True 29H without side tables MyBinding.com...
  • Page 3 Figure 1b. Installation of side tables 1. Right side table 2. Left side table 3. Cutter body 4. LED safety curtain cover right 5. LED safety curtain cover left 6. Washers (4 per side) 7. Fixing screws M8 (4 per side) MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124...

  • Page 4: Cutter Positioning

    Cutter positioning Figure 2. Leg adjustment To position the cutter safely, adjust the leveling foot as shown in Figure 2. Be sure to place the cutter on a solid, level surface. Keep the power cable away from walkways, to prevent a tripping hazard. Position the cutter so it's easy to operate safely, without requiring the user to reach an excessive distance or be in an uncomfortable position.

  • Page 5: Specifications

    2. SPECIFICATIONS The Cut-True 29H is designed to cut stacks of paper, cardboard and other materials - including plastic, foil, laminate, rubber etc - primarily in printing houses, bookbinding workshops and offices. Chart 1. CUT-TRUE 29H Maximum paper stack width (inch/mm) 20.5 / 520...

  • Page 6: External Dimensions

    External dimensions MyBinding.com 5500 NE Moore Court Figure 3a. External dimensions Hillsboro, OR 97124 Toll Free: 1-800-944-4573 Local: 503-640-5920...
  • Page 7 Figure 3b. MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 Local: 503-640-5920...

  • Page 8: Knife Drive

    Chart 2. Value DIMENSION (inch/mm) 49.6 / 1260 35.5 / 900 51 / 1300 54 / 1365 32 / 805 34 / 865 16 / 400 59.25 / 1505 62 / 1565 2.3 Construction The cutter consists of 3 basic mechanisms: knife drive, clamping beam mechanism, and back gauge mechanism, plus other additional devices.
  • Page 9 The driving mechanism for the knife is shown in Figure 4. Hydraulic Double-acting Cylinder/Actuator (1) is fixed on the Knuckle (2). Piston Rod (3) is connected with the Levers (4), which are connected with Connecting Rod (5), which pull Knife Beam (6) together with the knife.
  • Page 10 The driving mechanism for the clamping bar is shown in Figure 5. Hydraulic double- acting Cylinder/Actuator (1) through the Levers ( 2), pulls down the Clamping Bar ( 3). Clamping Bar is shifted in the slideways (not shown in Figure 5) , which guarantees it's parallel to the cutting line.

  • Page 11: Control System

    measure and check the position of the Backgauge with the use of the LED Cut Line (7). Two switches (9 and 10) stop the Backgauge in extreme positions. Precise setting of Backgauge is possible by using the Manual Crank (5). The Rotary Encoder (6) is connected with the Lead Screw (3) and allows for the measurement and display of the Backgauge position.
  • Page 12 3. The Red Stop Button (3) locks the machine, which immobilizes the control system 4. The Green Power Button (4) engages the control system. 5. Blade Change Button (5) has 2 positions: position “0”- normal work cycle (cutting) position “1”- blade change 6.

  • Page 13: Safety Hazards

    Drawing 8. Control system location The settings of encoders are imput by the manufacturer and should not be changed. 3. PROTECTION AGAINST SAFETY HAZARDS 3.1. Safety Hazards Potential hazards which result from the machine construction and usage as well as safety solutions used to eliminate these hazards are shown in chart 3.
  • Page 14 - stable shield 01.01.00 Motor, lever system of the knife 03.00.00 drive mechanism 10.00.00 - front table 08.00.00 03.00.00 - stable shield 5. Movement of the clamping beam 14.00.00 - light barrier 16.00.00 6. Movement of the backgauge - stable chart 00.00.30 - both hands protecting device...
  • Page 15 a) operator training – user has to be aware of potential danger, which he can meet during the work on the cutter b) use of the machine is prohibited if: - machine is used contrary to the use or/and cutting dimensions set in manual guide are exceeded - the machine is broken - at least one of the shields has been removed...
  • Page 16 a) operator training – user has to be aware of potential danger, which he can meet during the work on the cutter b) use of the machine is prohibited if: - machine is used contrary to the use or/and cutting dimensions set in manual guide are exceeded - the machine is broken - at least one of the shields has been removed...

  • Page 17: Preparation For Use

    4. PREPARATION FOR USE The operator is obligated to create on the machine working stand the conditions, which will eliminate the possibility of stumbling, sliding, falling down as a result of bad condition of background, the way the cables were lead or uncomfortable access to the machine.
  • Page 18 In order to switch the machine on, put main switch (1) into position 1. Then press the green button (2), which starts control system (green diode 3 will start to flash). If there is no object in the working area of the light barrier, green diode (4) will flash. If there is any object in the working area of light barrier, red diode (5) will flash.
  • Page 19 5.2 Clamping The cut material is being clamped automatically after pressing cut cycle buttons 1(drawing 12). Clamping pressure can be adjusted by crank 2 (d.12). Rotating clockwise cause pressure increase and anticlockwise decrease. Drawing 12. Location of the clamp pressure indicator A value of this force is evaluated experimentally, relating to the sort, width and the height of the cut material.
  • Page 20 Starting Point Drawing 12a. Following rules should be respected: the taller the pile, the greater the clam ping force the wider the cutting width, the greater the clam ping force the har der the material, the greater the clamping force 5.3 Cutting Drawing 13.

  • Page 21: Knife Change

    Before cut, check if there is any object in the working area of light barrier, green diode (1) flashes, main switch (2) is in position “O” and the green button (3) is switched on. If yes, cutting cycle will start after pressing at the same moment both buttons (4).
  • Page 22 turned to “I” position. 6.1.1.2 Press simultaneously both push-buttons 2 (drawing 14), starting the cutting cycle. The knife will stop in the lower position. 6.1.1.3 Switch-off the electric supply by rotating the main switch 4 (drawing 14) to “O” position. Drawing.15 6.1.1.4 Unscrew screws 1 (drawing 15) mounting the cover 2 and remove the cover Drawing.16...
  • Page 23 6.1.1.5 Unscrew and remove the screw 1, the first one to right side of the knife bar (drawing 16). 6.1.1.6 Turn on electric system by rotating the main switch 2 (drawing 16) into position I. Turn on cutter system by pressing the green button 3. 6.1.1.7 Rotary switch of knife change 4 (drawing 16) put into O position.
  • Page 24 Drawing 18. Drawing 19. Holding with the transporting clamps 1, release a clip, by rotating them by ½ turn to...

  • Page 25: Knife Installation

    left simultaneously, and put out the knife down with care. Place the removed knife into the special protective package (drawing 20), with the cutting edge to the inside, fix with two bolts, and unscrew the transporting clamps 1. For unscrewing the clamping screws of the knife to the knife bar, use Allen key (an accessory of the cutter) Drawing 20...
  • Page 26 WARNING: The new knife must be supported by its upper edge on the knife bar. Not obeying this rule may cause machine overload and possible damage if new knife is higher than the old one. Note: to avoid the knife cutting edge dent by the table surface, put a strips of cardboard or similar.
  • Page 27 Drawing 22. 6.1.2.3. Holding the screws 1 put the knife 2 into the cutter, and match the transporting screws into the knife bar gaps 3. (drawing 23) Drawing 23. Put the knife to Upper position until its up edge touches the bar lobe 2 (drawing 21).
  • Page 28 Drawing 24. 6.1.2.4 Mount the knife in the beam by rotating with force both screws 1 to the right (drawing 24) 6.1.2.5 Input the mounting screws 2 (drawing 24) 6.1.2.6 Unscrew both screws 1 (drawing 24) and put into its position mounting screws 1,2 (drawing 25) Drawing 25.
  • Page 29 6.1.2.7 Carefully unscrew rst screw (2) from the left (drawing 24) paying attention that the head of screw does not stick out the knife bar slide. 6.1.2.8 Rotate the knife change button (1, drawing 26) into “I” position. 6.1.2.9 Press simultaneously cutting buttons 2 (drawing 26) to start cut. Knife will stop in lower position.
  • Page 30 6.1.2.14. Turn on power supply by rotating button 3 into position „I” 6.1.2.15. Knife change button 1 rotate into O position. 6.1.2.16. Press simultaneously buttons 2. Knife will move into its upper position. 6.1.2.17. Turn off Power supply by rotating button 5 into O 6.1.2.18.
  • Page 31 6.2 Cutting stick change. The cutting quality of the bottom sheets and the rate at which the knife dull s depend s greatly on the cutting stick. Changing or rotating the stick is recommended after each change of the knife, or when bottom sheets are not completely cut. Drawing 28.
  • Page 32 Drawing 29. Cutting stick removal...
  • Page 33 Drawing 30. Stick usage The stick can be rotated 4 times In both planes to achieve 4 lines 1,2,3,4.(drawing 30) Note: Gap between the tables, where the stick is put, must be always clean. 6.3 Parallelism of backgauge If the backgauge is out of square (1), it is necessary to perform the adjustments shown on drawing 31.
  • Page 34 Drawing 31 Backgauge parallelism adjustment To adjust the bar, it is necessary: - to loosen both screws (1), fastening the pushing bar (4) to a slide; - to loosen nuts (2) - to set the pushing bar at appropriate angle, turning with adjusting screws (3) - to lock the adjusting screws (3) with nuts (2);...
  • Page 35 6.4 False clamp The false clamp can be installed in order to avoid creating marks by the clamp beam on the cut material. Drawing 32. False clamp False clamp is fixed under the front table (drawing 33). Drawing 33. False clamp location (when it is not installed in the clamping beam)
  • Page 36 In order to install the false clamp in the clamping beam: • press the buttons 1 (drawing 34) to move clamping beam 5 down • when the clamping beam will go down about 2 cm and uncover the holes for screws 4, release right button 1 (left button 1 should be still pressed) •...
  • Page 37 Drawing 34. Installing the false clamp in the clamping beam 7.MAINTANCE 7.1 Lubrication Location of lubrication points to be greased every week is shown on drawings 36,37,38. Access to the stated lubrication points is possible after dissembling the shield shown on the drawing 35 1.
  • Page 38 Drawing 35 Covers arrangements 7.1.1 Knife unit lubrication For the knife unit lubrication non-liquid grease have to be used. The following parts should be lubricated on the both parts of the cutter: 1. Side surfaces of the guides (contacted with the knife body) 2.
  • Page 39 Drawing 36 Location of the knife lubrication points. MyBinding.com 5500 NE Moore Court Hillsboro, OR 97124 Toll Free: 1-800-944-4573 Local: 503-640-5920...
  • Page 40 7.1.2 Backgauge lubrication In the backgauge mechanism the following parts must be lubricated: guiding roller (drawing 37 indicated with a triangle) and located under the roller lead screw (not marked on the drawing). This screw should be lubricated with the non-liquid grease, on the guiding roller, apply a thin coat of the grease.
  • Page 41 7.1.3 Clamping mechanism lubrication The parts of the clamping mechanism have to be lubricated with non-liquid grease. In the clamping mechanism the fo llowing parts should be lubricated: clamp bar runners (1) (drawing 37, signed with hexagon), roller bearing (2) (drawing 38), mounting point of hydraulic cylinder (drawing 38) .
  • Page 42 - air circulation for cooling - temperature of hydraulic oil should not exceed values given by supplier - the unit is designe d to work in a closed room, protected from any environmental conditions: direct sun, rain etc. - unit is designed to work in horizontal position - it should be used according to health and safety rules - unit should be maintained by quali ed sta Drawing 39.
  • Page 43 7.2. Inspections 7.2.1. General recommendations • Clean carefully machine after each work-shift /paper dust. • Pay attention to cleanness of the control element contacts /contractors, switches. • Check correctness of the cutter screw connections, and tighten them, if necessary. 7.3. Regeneration of knife Quality and accuracy of the cutting depends on the knife sharpness and the correct choice of the cutting edge angle 7.3.1 The features of blunt knife:...
  • Page 44 Drawing 40 Deviations and roughness of the knife. 7.3.3. Selection of the grinding angle Depending on the cut down material, a ground o angles are between 16 and 26 Soft material needs a smaller grinding angle, whereas a hard material, a larger grinding angle.

  • Page 45: Electrical Equipment

    8. ELECTRIC DOCUMENTATION 1 phase 230V 8.1 Electrical equipment 8.2 Electric table Symbol Quantity Name Type Manufacturer Contactor S-N12CX AC24V MITSUBISHI Tma 100VA BREVE – Transformer 220/24V TUFVASSO NS Fuse 3,15A S301 B4A Overload switch Schneider / Legrand S301 B6A Hydraulic motor S301 B16A Legrand...
  • Page 46 Motor 1X230V 50- 60Hz HKK 207 FCSP SIEMENS 1,5kW/1400 r/min Motor 3X400V 50- 60Hz Sg63 – 4B Tamel 0,18kW/1400 r/min LWE16-300 SG1F Emergency switch Adapter Z33E BACO SG2F Zestyk zw. 33E01 -2szt ENCODER Rotary encoder HTR-W-360-23-PP-SA20 HONTKO CO. Red LED Green LED LLM635003- Cutting Line indicator...
  • Page 47 8. ELECTRIC DOCUMENTATION 52H-2 phase 220V 8.1 Electrical equipment 8.2 Electric table Quantity Manufacturer Symbol Name Type Contactor S-N12CX AC24V MITSUBISHI BREVE – Transformer Tma 100VA 220/24V TUFVASSO NS iC60N 2P B25A iC60N 2P B16A Overload Schneider / iC60N 2P B10A switch Legrand iC60N 2P C4A...
  • Page 48 Motor 3X230V 50- 60Hz HK K 407A 90LB4 SIEMENS 1,5kW/1400 r/min Motor 3X230V 50- 60Hz Sg63 – 4B Tamel 0,18kW/1400 r/min Blower 1x230V 50- UNI JET 40 ESAM 60Hz LWE16-300 SG1F Emergency switch Adapter Z33E BACO SG2F Zestyk zw. 33E01 -2szt ENCODER Rotary encoder DBS36E-S3EK00600...
