- Page 1 ELECTRIC BASS AMP Owner‘s Manual BVH300...
- Page 2 Congratulations! We would like to thank you for purchasing the BVH300 Electric Bass Amplifi er. It has been specially designed and developed for the use with electric basses. Before using your new amplifi er, we advise to read the following pages carefully.
-
Page 3: Table Of Contents
Content Setting up the BVH300 ....................Peripheral Connections ....................Preamp Section ....................... Basics ..........................Mid Shift ........................... Controls & Switches ......................Special Gimmicks ......................Specifi cations ........................ -
Page 4: Setting Up The Bvh300
Setting up the BVH300 WARNING! To avoid electrical shock or any other damage, make sure that the BVH300 and all other devices are switched off before you start connecting them to the amplifi er! Power Connections/Mains Travelling Abroad Before connecting to a grounded power outlet,... -
Page 5: Peripheral Connections
With an optional footswitch (we recommend the have to be indentical. At an impedance of 4 ohms, FS100 by Fame) you are able to switch the amplifi er’s the connected cabinets need to have 8 ohms each boost function by foot. -
Page 6: Preamp Section
Basics With its fully vacoum tube powered electric circuit and the basic equa- lization, the BVH300 is the right amplifi er for bass players who are searching for a direct and fat-bottomed sound. It features a 3-band EQ as well as mid shift and boost functions, that will customize the basic sound of your bass exactly the way you like it. -
Page 7: Controls & Switches
You can choose between 4 or 8 ohms. sound of the amplifi er. Mid Shift This switch lowers the mid range of the BVH300. That means that low and high frequencies will be highligh- ted. The result will be a sound which is mostly used in... -
Page 8: Special Gimmicks
Analogue units will not harm the signal’s quality, but they are also limited and normally produce only one overall Due to the fact that the BVH300 does not feature an fx sound. loop, all effects devices have to be connected between instrument and amplifi... -
Page 9: Specifi Cations
Specifi cations 300 Watts Power Output: 6 x KT88 power amp, 5 x 12AX7 preamp Tubes: -10 dB, Boost, Mid Shift, Impedance, Power, Standby Switches: Equalization: Bass, Middle, Treble none Effects: Input Connection Jacks: Tuner Out Footswitch Parallel Speaker Jacks Balanced Out Dimensions: 55,9 x 25,4 x 30,5 cm... - Page 10 BVH300 2007...
