Summary of Contents for FAME G20D2
- Page 1 ELECTRIC GUITAR AMP Owner‘s Manual G20D2...
-
Page 2: Safety Warnings
Congratulations! We would like to thank you for purchasing the G20D2 Electric Guitar Amplifi er. It has been specially designed and developed for the use with electric guitars. Before using your new amplifi er, we advise to read the following pages carefully. -
Page 3: Table Of Contents
Content Setting up the G20D2 ..................... Peripheral Connections ....................Preamp Section ....................... Controls & Switches ......................DSP Effects ........................Special Gimmicks ......................Specifi cations ........................ -
Page 4: Setting Up The G20D2
Setting up the GS2-158D WARNING! To avoid electrical shock or any other damage, make sure that the G20D2 and all other devices are switched off before you start connecting them to the amplifi er! Power Connections/Mains Main Fuse Before connecting to a grounded power outlet, make... -
Page 5: Peripheral Connections
CONNECTIONS ON THE BACK Mains This jack is used to connect the G20D2 to a grounded power outlet. Please make sure that the power cord works correctly and has a shielded plug. CD In... -
Page 6: Controls & Switches
These three knobs represent the master equaliza- Switches the GS2-158D on or off. tion of the G20D2. Treble controls the amount of high frequencies in the overall sound, while Midd- le and Bass are responsible for the mid and low... -
Page 7: Dsp Effects
DSP Effects In this chapter we will introduce the built-in DSP effects. The programms available are the most known and used actually. DIGITAL EFFECTS IN THE G20D2 Delay Chorus The orginal signal will be repeated with a settable lag Produces a classical chorus effect. A second sig- nal with a slight detune and delay is added to the of time. -
Page 8: Special Gimmicks
Rotary or Vibe Analogue units will not harm the signal’s quality, but they Due to the fact that the G20D2 does not feature a built- are also limited and normally produce only one overall in fx-loop, all effect devices will always have to be sound. -
Page 9: Specifi Cations
Specifi cations 20 Watts Power Output: 1 x 8“ Special Design Speakers: Clean/Overdrive, Mains Switches: Equalization: Bass, Middle, Treble Digital effects with 4+2 programms (4 x modulation, delay, reverb) Effects: Input Connection Jacks: Phones CD In 31,1 x 32,2 x 21 cm Dimensions: Weight: 7 kg... - Page 10 G20D2 2008...
