Artusi CAGH6000B Installation And User Manual

Built-in stainless steel gas hob

Advertisement

Built-in Stainless Steel Gas Hob
MODELS: CAGH6000B
CAGH7000B
CAGH9000B

Advertisement

loading
Need help?

Need help?

Do you have a question about the CAGH6000B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Artusi CAGH6000B

  • Page 1 Built-in Stainless Steel Gas Hob MODELS: CAGH6000B CAGH7000B CAGH9000B...
  • Page 2: Table Of Contents

    Installation and User manual Contents Safety ---------------------------------------------------- 1 Product description---------------------------------- 4 Installation------------------------------------------------6 Start using your appliance--------------------------11 Maintenance and troubleshooting----------------13 Warranty------------------------------------------------ 14...
  • Page 3: Safety

    This manual explains the proper installation and use of your appliance, please read it carefully before using even if you are familiar with the product. The manual should be kept in a safe place for future reference. In case of failure, only the Authorized Technical Service may repair this hob.
  • Page 4 (e.g. plastic film, plastic, aluminum) on or near the appliance.  Never heat empty pans on the appliance. Children’s Safety  The cooking zones will become hot when you cook. Always keep small children away from the appliance.  The appliance is not intended for use by young children or infirm persons without supervision.
  • Page 5 to ensure it corresponds to the installation gas supply. If in doubt contact the supply authority.  The power supply cord (supplied) must not touch any hot surfaces and must be placed so that its temperature does not exceed 75 degrees at any point along its length. ...
  • Page 6: Product Description

    Panel knobs Model Burner* Knob Total gas Over view supports position consumption LPG: 1W+2SR+1A With Cast Iron Front 29.6MJ/h CAGH6000B 29.0MJ/h LPG: Cast Iron 1W+1R +2SR+1A With Front 39.6MJ/h CAGH7000B 39.0MJ/h LPG: 1W+1R +2SR+1A With Cast Iron Front 39.6MJ/h CAGH9000B 39.0MJ/h...
  • Page 7 Technical Specifications Product Cut-out Electrical Rated Model Dimensions Size Connection Input (h x w x d) mm ( w x d)mm Power CAGH6000B 584x510x100 552 x 470 220-240V/50Hz 0.5W CAGH7000B 684x510x100 552 x 470 220-240V/50Hz 0.5W CAGH9000B 874x510x100 552 x 470 220-240V/50Hz 0.5W...
  • Page 8: Installation

    Installation Before Installation:  Before cutting into any bench tops, ensure the minimum clearances to walls, adjacent surfaces and overhead surfaces required by the relevant gas appliance installation code (see above) will comply. Dimensions are specified in millimeters (mm) Overhead cupboards and range hood = 650 mm. Side and rear clearance = 200 mm to any burner edge.
  • Page 9 1. Cupboard Cutting Bench top thickness, 30– 40 mm (3 – 4 cm). CAGH6000B CAGH7000B CAGH9000B 2. Place Burner Box Apply the adhesive sealing tape to the underside lip of the burner box. Shown at G opposite. Place burner box into cutout hole and fit clamping brackets to clamp the hotplate to the bench.
  • Page 10 75℃ at any point along its length. After having installed the hotplate, the GPO must always be in an accessible position. Wiring diagram CAGH6000B CAGH7000B, CAGH9000B 4. Gas Connection Install in accordance with relevant gas standards and/or codes of practice applicable.
  • Page 11 Ensure the supply connection point, test point and natural gas regulator adjustment screw (for Natural gas installation) are accessible for testing and/or adjustment with the hotplate in the installed position. Where a flexible hose assembly is used, ensure it is approved to AS/NZS 1869, Class B.
  • Page 12 manual. 5. If the pressure is not 2.75kPa, disconnect the appliance and check/adjust/replace the LPG cylinder regulator(s) as appropriate in accordance with AS/NZS 5601. ADJUSTING THE BURNER MINIMUM FLAME HEIGHT: NOTE: This adjustment can only be performed by the installer or by authorised service personnel. The minimum burner flame is factory adjusted for the gas type stated on the gas type label adjacent to the gas connection and should not require adjustment.
  • Page 13: Start Using Your Appliance

    Start Using Your Appliance CAGH6000B CAGH7000B, CAGH9000B Description Explanation These show which zone is under control. Zone indicators Flame power Flame power of the zones, is the lowest and is the highest. The hotplates are fitted with mains powered electronic spark ignitors, so must be connected to mains power supply (i.e.
  • Page 14 with burner lighting persist, refer to the TROUBLESHOOTING section of these instructions. If power is not available, light a match or similar, then turn the gas control knob for the burner to be lit, to the High Flame setting. Once again if problems with burner lighting persist, refer to the TROUBLESHOOTING section of these instructions.
  • Page 15: Maintenance And Troubleshooting

    Maintenance & Troubleshooting Cleaning and maintenance should be carried out with the appliance cold especially when cleaning the enameled parts. Avoid leaving alkaline or acid substances (lemon juice, vinegar etc.) on the surfaces. STAINLESS STEEL The stainless steel hob of the hotplate must be cleaned regularly (e.g. weekly) to ensure long life expectancy of the hotplate.
  • Page 16: Warranty

    TROUBLESHOOTING Servicing of the hotplates must only be done by an authorised service representative (see back of this booklet) and the hotplate must not be modified. Power must be disconnected before any servicing or maintenance is conducted. DO NOT MODIFY THIS APPLIANCE. It is recommended the hotplate serviced by an authorized person at least every 2 years.
