Artusi CACC90 Operation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AP PL I ANC ES
FO R L I VI NG
CACC90
OPERATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CACC90 and is the answer not in the manual?

Questions and answers

Related Manuals for Artusi CACC90

Summary of Contents for Artusi CACC90

  • Page 1 AP PL I ANC ES FO R L I VI NG CACC90 OPERATION MANUAL...
  • Page 2 ARTUSI Family. This instruction manual has been specially created to inform you of the full range of features your ARTUSI appliance has to offer and serves as an introduction to getting the very best out of your ARTUSI appliance.

  • Page 3: Safety Warnings

    Safety Warnings Your safety is important to us. Please read this information before using your cooktop. Installation Electrical Shock Hazard • Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. • Connection to a good earth wiring system is essential and mandatory.
  • Page 4 • No combustible material or products should be placed on this appliance at any time. • Please make this information available to the person responsible for installing the appliance as it could reduce your installation costs. • In order to avoid a hazard, this appliance must be installed according to these instructions for installation.

  • Page 5: Health Hazard

    contact a qualified technician. • Switch the cooktop off at the wall before cleaning or maintenance. • Failure to follow this advice may result in electrical shock or death. Health Hazard • This appliance complies with electromagnetic safety standards. Hot Surface Hazard •...
  • Page 6 out of reach of children. • Failure to follow this advice could result in burns and scalds. Cut Hazard • The razor-sharp blade of a cooktop scraper is exposed when the safety cover is retracted.Use with extreme care and always store safely and out of reach of children.
  • Page 7 by using the touch controls). Do not rely on the pan detection feature to turn off the cooking zones when you remove the pans. • Do not allow children to play with the appliance or sit, stand, or climb on it. •...
  • Page 8 • Do not stand on your cooktop. • Do not use pans with jagged edges or drag pans across the Induction glass surface as this can scratch the glass. • Do not use scourers or any other harsh abrasive cleaning agents to clean your cooktop, as these can scratch the Induction glass.
  • Page 9 •This appliance can be used by children aged from 8 years and above and persons with reduced physical,sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

  • Page 10: Product Overview

    Congratulations on the purchase of your new Ceramic Hob. We recommend that you spend some time to read this Instruction / Installation Manual in order to fully understand how to install correctly and operate it. For installation, please read the installation section. Read all the safety instructions carefully before use and keep this Instruction / Installation Manual for future reference.

  • Page 11: Product Information

    Product Information The microcomputer ceramic cooker hob can meet different kinds of cuisine demands because of resistance wire heating, micro-computerized control and multi-power selection, really the optimal choice for modern families. The ceramic cooker hob centers on customers and adopts personalized design. The hob has safe and reliable performances, making your life comfortable and enabling to fully enjoy the pleasure from life.

  • Page 12: Using Your Ceramic Hob

    Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Always centre your pan on the cooking zone. Always lift pans off the ceramic hob – do not slide, or they may scratch the glass. Using your Ceramic Hob To start cooking •...

  • Page 13: When You Have Finished Cooking

    3. Touching the heating zone selection control, and a indicator next to the key will flash. 4. Ajust heat setting by touching the the slider control. • If you don’t choose a heat setting within 1 minute, the ceramic hob will automatically switch off.
  • Page 14 3. Turn the whole cooktop off by touching the ON/OFF control. 4. Beware of hot surfaces “H” will show which cooking zone is hot to touch. It will disappear when the surface has cooled down to a safe temperature. It can also be used as an energy saving function if you want to heat further pans, use the hotplate that is still hot.

  • Page 15: Locking The Controls

    2. the power level indicator flash, then press ”◎” , after 5 seconds, the indicator stop flash, the double loop function is activate, and power level shows “6” and “=” alternately. Deactivate the double zone 1.Press the heating zone selection control of the double loop heating zone, the power level indicator flash, then press”...

  • Page 16: Over Temperature Protection

    When the hob is in the lock mode, all the controls are disable except the ON/OFF you can always turn the ceramic hob off with the ON/OFF control in an emergency, but you shall unlock the hob first in the next operation Over-Temperature Protection A temperature sensor equipped can monitor the temperature inside the ceramic hob.
  • Page 17 Touch timer control , the “10” will show in the timer display. and the “0” fiashes. 2. Set the time by touching the slider control. (e.g. 5) 3. Touch timer control again, the “1” will flash. 4. Set the time by touching the slider control (e.g.9), now the timer you set is 95 minutes.

  • Page 18: Setting The Timer To Turn One Or More Cooking Zones Off

    Setting the timer to turn one or more cooking zones If the timer is set on one zone: 1. Touching the heating zone selection control that you want to set the timer for. 2. Touch timer control , the “10” will show in the timer display.

  • Page 19: Cooking Guidelines

    5. When the time is set, it will begin to count down immediately. The display will show the remaining time NOTE: The red dot next to power level indicator will illuminate indicating that zone is selected. 6. When cooking timer expires, the corresponding cooking zone will be switch off automatically.

  • Page 20: For Stir-Frying

    2. Heat up a heavy-based frying pan. 3. Brush both sides of the steak with oil. Drizzle a small amount of oil into the hot pan and then lower the meat onto the hot pan. 4. Turn the steak only once during cooking. The exact cooking time will depend on the thickness of the steak and how cooked you want it.

  • Page 21: Care And Cleaning

    Care and Cleaning What? How? Important! Everyday soiling on 1. Switch the power to the • When the power to the cooktop is glass (fingerprints, cooktop off. switched off, there will be no ‘hot marks, stains left by 2. Apply a cooktop cleaner surface’...

  • Page 22: Hints And Tips

    This is normal for cookware and crackling or clicking construction of your cookware does not indicate a fault. noises. (layers of different metals vibrating differently). Technical Specification Cooking Hob CACC90 Cooking Zones 5 Zones Supply Voltage 220-240V~ Installed Electric Power 7600-9200W Product Size L×W×H(mm)

  • Page 23: Selection Of Installation Equipment

    Selection of installation equipment Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 50mm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant work surface material to avoid larger deformation caused by the heat radiation from the hotplate.

  • Page 24: Before Locating The Fixing Brackets

    A(mm) B(mm) C(mm) 50 mini 30 mini Air intake Air exit 10 mm Before locating the fixing brackets The unit should be placed on a stable, smooth surface (use the packaging). Do not apply force onto the controls protruding from the hob. Fix the hob on the work surface by screw four brackets on the bottom of hob (see picture) after installation.

  • Page 25: Connecting The Hob To The Mains Power Supply

    heat. 5. To avoid any damage, the sandwich layer and adhesive must be resistant to heat. 6. A steam cleaner is not to be used. 7. This ceramic can be connected only to a supply with system impedance no more than 0.427 ohm.
  • Page 26 1. If the cable is damaged or needs replacing, this should be done by an after-sales technician using the proper tools, so as to avoid any accidents. 2. If the appliance is being connected directly to the mains supply, an omnipolar circuit breaker must be installed with a minimum gap of 3mm between the contacts.
  • Page 27 Office: 2. What is not Covered by the Warranty. 48-50 Moore Street, Leichhardt N.S.W 2040 The Warranty does not apply if an artusi product Post: is defective by a factor other than a defect arising Locked Bag 3000, Annandale, N.S.W 2038...
  • Page 28 Last Name: First Name: Address: State: Postcode: Email: Home Phone: Mobile: Purchase Date: (Please attach proof of purchase to validate warranty) SERIAL NUMBER MODEL NUMBER (if you cannot locate the serial number please call ARTUSI on 1300 694 583) 01032014...
  • Page 30 Product dimensions indicated in our literature is indicative only. Actual product only should be used to define dimension cutouts. Distributors, and retailers are not agents of ARTUSI and are not authorised to bind ARTUSI by any express or implied undertaking or representation.
