- Page 1 TOUCH CONTROL INDUCTION HOB Instruction Manual / Installation Manual CAID646B MODEL: V20221010...
-
Page 2: Table Of Contents
Content 1. Foreword ..................4 1.1 Safety Warnings ................. 4 1.2 Installation ................4 1.2.1 Electrical Shock Hazard ..........4 1.2.2 Cut Hazard ..............4 1.2.3 Important safety instructions .......... 4 1.3 Operation and maintenance ............6 1.3.1 Electrical Shock Hazard ..........6 1.3.2 Health Hazard .............. - Page 3 9.7 Connecting the hob to the mains power supply ......24 10. Warranty Card……………………………………………………………………….. 27 [键入文字]...
-
Page 4: Foreword
1. Foreword 1.1 Safety Warnings Your safety is important to us. Please read this information before using your cooktop. 1.2 Installation 1.2.1 Electrical Shock Hazard Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. ... - Page 5 from the power supply. Failure to install the appliance correctly could invalidate any warranty or liability claims. This appliance is not intended for use by persons(including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 6: Operation And Maintenance
Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire. NEVER try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. -
Page 7: Hot Surface Hazard
1.3.3 Hot Surface Hazard During use, accessible parts of this appliance will become hot enough to cause burns. Do not let your body, clothing or any item other than suitable cookware contact the Induction glass until the surface is cool. ... - Page 8 competent person to instruct them in its use. The instructor should be satisfied that they can use the appliance without danger to themselves or their surroundings. Do not repair or replace any part of the appliance unless specifically recommended in the manual. All other servicing should be done by a qualified technician.
-
Page 9: Product Introduction
2. Product Introduction 2.1 Top View 1. Max. 1400/1500W zone 2. Max. 2400/2600W zone 3. Max. 1800/2000W zone 4. Max. 1800/2000W zone 5. Glass plate 6. Control panel 2.2 Control Panel 1. On/Off control 2. Keylock control 3. Boost control 4. -
Page 10: Before Using Your New Induction Hob
Read this guide, taking special note of the ‘Safety Warnings’ section. Remove any protective film that may still be on your Induction hob. 2.5 Technical Specification Cooking Hob CAID646B Cooking Zones 4 Zones Supply Voltage 220-240V~ or 380-415V~, 50Hz or 60Hz... -
Page 11: How To Use
Do not use cookware with jagged edges or a curved base. Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking zone. Use pans whose diameter is as large as the graphic of the zone selected. Using a pot a slightly wider energy will be used at its maximum efficiency. -
Page 12: If The Display Flashes
Select a heat setting by touching the “-” or “+” control. • If you don’t choose a heat setting within 1 minute, the Induction hob will automatically switch off. You will need to start again at step 1. • You can modify the heat setting at any time during cooking. -
Page 13: Locking The Controls
Touching the boost control , the zone indicator show “P” and the power reach Max. Cancel the Boost function Touching the "Boost" control or the “-” button to cancel the Boost function, then the cooking zone will revert to its original setting. -
Page 14: Using The Timer As A Minute Minder
a) Using the Timer as a Minute Minder If you are not selecting any cooking zone Make sure the cooktop is turned on. Note: you can use the minute minder at least one zone shall be active. Touch the controls of the timer. The minder indicator will start flashing and “10”... -
Page 15: Default Working Times
Touching the “-” and “+” together, the timer is cancelled, and the “00” will show in the minute display. When the time is set, it will begin to count down immediately. The display will show the remaining time and the timer indicator flash for 5 seconds. -
Page 16: Cooking Guidelines
People with a heart pace maker should consult with their doctor before using this unit. 4. Cooking Guidelines Take care when frying as the oil and fat heat up very quickly, particularly if you’re using PowerBoost. At extremely high temperatures oil and fat will ignite spontaneously and this presents a serious fire risk. -
Page 17: Detection Of Small Articles
4.2 Detection of Small Articles When an unsuitable size or non-magnetic pan (e.g. aluminium), or some other small item (e.g. knife, fork, key) has been left on the hob, the hob automatically go on to standby in 1 minute. The fan will keep cooking down the induction hob for a further 1 minute. -
Page 18: Hints And Tips
Boilovers, melts, Remove these immediately with a fish • Remove stains left by melts and slice, palette knife or razor blade sugary food or spillovers as soon hot sugary spills on scraper suitable for Induction glass as possible. If left to cool on the the glass cooktops, but beware of hot cooking glass, they may be difficult to... -
Page 19: Failure Display And Inspection
The induction hob This is caused by the technology This is normal, but the noise should makes a low humming of induction cooking. quieten down or disappear completely noise when used on when you decrease the heat setting. a high heat setting. Fan noise coming from A cooling fan built into your This is normal and needs no action. - Page 20 --open circuit. Temperature sensor of the IGBT failure --short circuit Wait for the temperature of IGBT return to normal. High temperature of IGBT. Touch “ON/OFF” button to restart unit. Check whether the fan runs smoothly; if not , replace the fan. Please inspect whether power supply is Supply voltage is below the rated voltage.
-
Page 21: Installation
Push “ON/OFF” button to restart unit. Heating zones of the same The power board and Check the connection. side ( Such as the first and the display board the second zone ) would connected failure; display “u” . The display board of Replace the display communicate part is board. - Page 22 Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760 mm. A(mm) B(mm) C(mm) 50 min. 20 min. Air intake Air exit 5mm WARNING: Ensuring Adequate Ventilation Make sure the induction cooker hob is well ventilated and that air inlet and outlet are not blocked. In order to avoid accidental touch with the overheating bottom of the hob, or getting unexpectable electric shock during working, it is necessary to put a wooden insert, fixed by screws, at a minimum distance of 50mm from the bottom of the hob.
-
Page 23: Before Installing The Hob, Make Sure That
9.2 Before installing the hob, make sure that The work surface is square and level, and no structural members interfere with space requirements. The work surface is made of a heat-resistant and insulated material. If the hob is installed above an oven, the oven has a built-in cooling fan. ... -
Page 24: Cautions
Under any circumstances, the brackets cannot touch with the inner surfaces of the worktop after installation (see picture) 9.6 Cautions 1. The induction hotplate must be installed by qualified personnel or technicians. We have professionals at your service. Please never conduct the operation by yourself. 2. - Page 25 3. The power supply cable sections can withstand the load specified on the rating plate. To connect the hob to the mains power supply, do not use adapters, reducers, or branching devices, as they can cause overheating and fire. The power supply cable must not touch any hot parts and must be positioned so that its temperature will not exceed 75˚C at any point.
- Page 26 The bottom surface and the power cord of the hob are not accessible after installation. The symbol on the product, or in its packaging, indicates that this product may not be treated as household wasted, Instead, it should be taken to the appropriate waste collection point for the recycling of electrical and electronic equipment.
