Winston Industries CVap HBK Series Use & Care Manual

Hold & serve drawer

Advertisement

hold & serve drawer
HBK Series
Hold & Serve Drawer
Use & Care Manual
HBK5D1
Built with pride by
4272Y363
R12
rs
04-28-09
www.winstonind.com • 800-234-5286

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CVap HBK Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Winston Industries CVap HBK Series

  • Page 1 hold & serve drawer HBK Series Hold & Serve Drawer Use & Care Manual HBK5D1 Built with pride by 4272Y363 04-28-09 www.winstonind.com • 800-234-5286...
  • Page 2: Table Of Contents

    Mail: 2345 Carton Drive • Louisville, KY 40299 USA. Copyright© 2009 Winston Industries LLC. All rights reserved. CVap is a registered trademark of Winston Industries LLC. The CVap logo is a trademark of Winston Industries LLC. All other company and product names may be trademarks of their respective companies.
  • Page 3: Safety

    hold & serve drawer drawers or reaching into the appliance, as Please read this entire use & care manual heated vapor can quickly cause burns. before operating your CVap hold & serve ® drawer. The manual contains important safety information and operating instructions. Contamination Hazard As is the case with many kitchen Can cause serious illness or damage to...
  • Page 4: Receiving Your Appliance

    hold & serve drawer carrier should agree to inspect the damage receiving your appliance within 15 days. Please retain all packing materials. The carrier will supply an Shipping Damage inspection report and the required claim Examine equipment thoroughly for shipping forms.
  • Page 5: Electrical Information

    hold & serve drawer electrical necessary for a licensed electrician to install the correct outlet or wiring. Winston does not The appliance is shipped from the factory recommend wiring the appliance direct. with a 84" (213cm) minimum power cord and plug.
  • Page 6: Component Identification

    hold & serve drawer component identification 7. Drawer Gasket seals food chamber 1. Drawer(s) 6" (152mm) deep for holding against heat or vapor loss. one full size, two half size, or three third size pans. 8. Evaporator (not visible in photo) located inside the base, supplies vapor to food 2.
  • Page 7: Controls

    hold & serve drawer controls Some details have been omitted for clarity. the food temp setting will provide a moist 1. Power Switch controls electrical power to texture. Elevating the texture setting will the appliance. deliver a progressively drier and crisper texture.
  • Page 8: Daily Operating Instructions

    hold & serve drawer concentrated proteins and salts to deposit in daily operating procedures the evaporators, potentially causing corrosion. This can void your warranty. The HBK controller allows you to set a single food temperature and texture for the entire Contamination Hazard appliance.
  • Page 9: Programming

    hold & serve drawer The controller allows the user to set a single hbk programming food temperature and texture for the entire These appliances are factory programmed to appliance. The eight channel keys allow the hold crisp foods. The default settings are: user to set eight different timed cycles for the Timer = 30 minutes, Food Temp = 100ºF set temperature.
  • Page 10: Programming

    hold & serve drawer NOTES COMPUTER DISPLAY PRESS KEY/ACTION Use arrow keys to adjust the STEP 7  Food Texture setting. Hold  either key down for fast scrolling (0 to 210˚F (32 to 99ºC)). 300˚F (149ºC) maximum when added to Food Temp setting.
  • Page 11: Holding Guidelines

    hold & serve drawer holding guidelines - HBK series CELSIUS CELSIUS FAHR EN HEIT FAHR EN HEIT PRODUCT Food Food Food Food PRODUCT Food Food Food Food Temp Texture Temp Texture Temp Texture Temp Texture C° C° F° F° F° C°...
  • Page 12: Daily Cleaning

    hold & serve drawer daily cleaning Required Cleaning Accessories & Supplies • Pan for draining evaporator • Food grade germicidal detergent Corrosion Hazard • Descaling agent (ScaleKleen™) Can cause damage to appliance. Clean appliance daily to avoid potential corrosion (available through Winston Customer damage.
  • Page 13 hold & serve drawer 5. Inspect for scale build-up on the tank daily cleaning procedure surface, water level sensor, and probe (see photo below). If present, apply descaling agent. Read ALL warnings and follow directions listed on descaling agent package. Burn Hazard Can cause injury.
  • Page 14 hold & serve drawer 7. Inspect heating elements (if exposed). The elements are stainless steel. If cleaning is needed, scrub with Teflon ™ nylon bristle brush to remove heavy food particles. Further cleaning may be done with a plastic scouring pad and alkaline based cleansers.
  • Page 15: Troubleshooting

    If the problem you're experiencing from the factory online. isn't listed, or if the standard solution fails to Visit www.winstonind.com Please have the following information on hand when contacting Winston Industries regarding product service. 1. Model _____________________Serial # _____________________________________ (located on name plate) 2.
  • Page 16 hold & serve drawer troubleshooting TROUBLE FAULT CODE Digital display fails to light ................A Digital display reading inconsistently ............... J Flooding/leaking water ..................C, H, I Food drying out ....................B, E, F, H Food excessively moist ..................D, G Food not hot enough ..................
  • Page 17 hold & serve drawer 2. Use nut driver and open-end wrench to troubleshooting remove drawer rollers and replace with new components. How to Tell if Unit is Working Properly 3. Tighten roller bolts with open-end wrench 1. Preheat unit for 30 minutes. and nut driver.
  • Page 18: Troubleshooting

    hold & serve drawer This appliance utilizes high voltage troubleshooting electrical systems, high temperature heating systems, and hot water vapor. If used improperly, any of these hazards are capable of causing serious injury or death. To avoid the potential for an Electrical Hazard accident, please have appliance installed Can cause serious injury or death.
  • Page 19: Circuit Diagram

    hold & serve drawer circuit diagram - HBK series www.winstonind.com • 800-234-5286...
  • Page 20: Zap Warranty

    ZAP WARRANTY AGREEMENT This warranty agreement applies to commercial equipment, equipment service parts, and safety parts (collectively, "Products") manufactured by Winston Industries, LLC ("Winston") and its corporate predecessors and is extended to any purchaser, lessee or successor purchaser ("Purchaser"). NEW EQUIPMENT...
  • Page 21: Terms & Conditions

    TERMS AND CONDITIONS OF SALE In consideration of the mutual benefits hereby to be derived, Winston Industries, LLC (“Winston”) and any purchaser, lessee or successive purchaser ("Purchaser"), of Winston Commercial Equipment, Equipment Service Parts, and Safety Parts (collectively “Products”) agree that: 1.
