- Page 1 R2020 Video Infrared Thermometer Instruction Manual www.REEDINSTRUMENTS.com REED-Direct.ca info@REED-Direct.ca 1.800.561.8187...
-
Page 2: Table Of Contents
Table of Contents Introduction ....................4 Product Quality ................... 4 Safety ......................4 Features ...................... 4 Specifications ..................5-6 Included ...................... 7 Instrument Description ................7 Operating Instructions ................8-17 Main Menu .....................8-11 IR Camera Mode .................. 8 IR Measurement Mode ................. 9 Dew Point Measurement Mode ............ - Page 3 Enable or Disable the Audible Beep ........... 14 Enable or Disable the Auto-Screen off Function ........ 14 Enable or Disable the Auto-Power off Function ......... 14 Restoring Default Settings ..............14 Measurement Settings ..............15-17 Adjusting Emissivity ................15 Setting the High Alarm Value .............. 16 Setting the Low Alarm Value ..............
-
Page 4: Introduction
Introduction Thank you for purchasing your REED R2020 Video Infrared Thermometer. Please read the following instructions carefully before using your instru- ment. By following the steps outlined in this manual your meter will provide years of reliable service. Product Quality... -
Page 5: Specifications
Specifications IR Temperature Range: -58 to 3992°F (50 to 2200°C) Accuracy: -58 to 68°F (-50 to -20°C): ± 6.3°F(3.5°C) 68 to 932°F (20 to 500°C ): ±1% rdg. +1.8°F (1.0°C) 932 to 1832°F (500 to 1000°C): ±1.5% rdg. 1832 to 3992°F (1000 to 2200°C): ±2.0% rdg. Resolution: 0.1°F (0.1°C) Contact Type K T/C Temperature Range: -58 to 2498°F (-50 to 1370°C) Accuracy: -58 to 32°F (-50 to 0°C): ±4. 5°F (2.5°C) 32 to 2498°F (0 to 1370°C): ±0.5% rdg. + 2.7°F (1.5°C) Resolution: 0.1°F (0.1°C) Ambient Temperature Range: 32 to 122°F (0 to 50°C) Accuracy: 50 to 104°F (10 to 40°C): ±0.9°F (0.5°C) >104°F (40°C): ±1.8°F (1.0°C) Dewpoint and Wet Bulb Temperature Range: 32 to 122°F (0 to 50°C) Accuracy: <40°C: ±0.9°F (0.5°C) >40°C: ± 1.8°F (1.0°C) - Page 6 General Specifications Optical Resolution (D:S): 50:1 Dual Laser: Spectral Response: 8 to 14µm Emissivity: 0.1 to 1.0 (Adjustable) Response Time: 150ms Display Size/Type: 2.2" TFT Color LCD Backlit Display: Display Hold: High/Low Alarms: Yes (Audible (beep) and visual (on-screen)) Max/Min: Average and Differential: Datalogging Capabilities: F/C Switchable: Trigger Lock: Autoshut off: Yes (adjustable 3,15,60mins) Internal Memory: Yes (72mb), Expandable with micro SD card Thermocouple Input: Tripod Mountable:...
-
Page 7: Included
Included • Type K Thermocouple Probe • AC Adapter • USB Adapter • Mini-Tripod • Hard Carrying Case • Li-ion Rechargeable Battery Instrument Description 1. Lens Cover 9. Type-K Thermocouple Jack 2. LCD Display 10. USB Computer Interface Jack 3. Front Panel 11. Micro SD Memory Card Slot 4. Trigger 12. Battery 5. Battery Cover 13. Up/Picture Button 6. Camera 14. Power/ESC Button 7. -
Page 8: Operating Instructions
Operating Instructions Main Menu When you turn the meter on you will enter the main menu screen by default. Press the buttons to scroll through the following parameters. IR Camera Mode Data Logger Mode IR Measurement Mode Media Gallery Dew Point Measurement Mode Settings Once the appropriate parameter has been selected follow the asso- ciated instructions below. -
Page 9: Ir Measurement Mode
IR Measurement Mode The IR Measurement mode measures IR temperature, air temperature, relative humidity, Dew point temperature, and wet bulb temperature without the video camera capabilities. Press the ENTER button when "IR Measure" is highlighted to enter IR measurement mode. Once the measurement settings are configured (see "Measurement Settings" for details), press and hold the trigger to take a measurement. Note: This function is best suited for quick measurements. Dew Point Measurement Mode The Dew Point Measurement mode measures IR temperature, air temper- ature, relative humidity, Dew point temperature, and wet bulb temperature. -
Page 10: Media Gallery
Media Gallery The media gallery mode allows a user to view the saved pictures, videos or logs. Press the ENTER button when ‘GALLERY' is highlighted to enter the saved media gallery. Press the buttons to scroll through the media gallery folders (Video, Picture or logs) Once the appropriate folder has been selected follow the associated instructions below. -
Page 11: Viewing Logs
Press the buttons to select between Yes or No and press the ENTER button to confirm selection Press the ESC button twice to exit the video thumbnails and return to the media gallery folders. Viewing Logs Press the ENTER button when 'Logs' is highlighted to enter the saved logs gallery. -
Page 12: System Settings
Enable or disable the auto-screen off function Auto power-off Enable or disable the auto-power off function System Default Setting Restores the R2020 to its default settings Once the appropriate parameter has been selected follow the associated instructions below. Setting the Language Press the ENTER button when "Languages"... -
Page 13: Setting The Time And Time Format
Once the format has been chosen, press the buttons to select the day, month and year while pressing the ENTER button to confirm each entry. Press the ESC button to exit the date/format function and return to system settings. Setting the Time and Time Format Press the ENTER button when "Time/Format"... -
Page 14: Enable Or Disable The Audible Beep
Enable or Disable the Audible Beep Press the ENTER button when ‘Beeper' is highlighted to enter the appropriate function. Press the buttons to select between On or Off Press the ENTER button to confirm selection. Press the ESC button to exit the audible beep function and return to system settings. -
Page 15: Measurement Settings
Measurement Settings While taking a measurement, press the ENTER button to open the "Measurement Settings" menu. Press the buttons to scroll through the following parameters. Parameter Description Emissivity Adjusting the emissivity value Alarm High Setting high temperature alarm Alarm Low Setting low temperature alarm Laser Enable or Disable the laser indicator Auto Mode Enable or disable automatic measurement mode Max/Min... -
Page 16: Setting The High Alarm Value
Setting the High Alarm Value Press the ENTER button when "Alarm High" is highlighted to enter the appropriate function. Press the buttons to enable, disable or set the alarm value. Press the ENTER button to confirm selection. Press the buttons to adjust the value. (if applicable) Press the ESC button to save and exit the high alarm value (if applicable). -
Page 17: Average/Differential Ir Temperature Values
Average/Differential IR Temperature Values While "Average/Dif" is highlighted in measurement settings, press the ENTER button to set the average and differential IR temperature values ON or OFF. Dew-point/Wet Bulb Temperature Values While "Ambient Temp/%RH" is highlighted in measurement settings, press the ENTER button to set the dew point and wet bulb temperature values ON or OFF. -
Page 18: Appendix: Emissivity Chart
Appendix: Emissivity Chart Emissivity is a term used to describe the energy-emitting characteristics of materials. Most (90% of typical applications) organic materials and painted or oxidized surfaces have an emissivity of 0.95. Inaccurate readings will result from measuring shiny or polished metal surfaces. To compensate, cover the surface to be measured with masking tape or flat black paint. - Page 19 Measured Surfaces Emissivity Steel: Cold Rolling, Steel Plate Burnishing, 0.7-0.9, 0.4-0.6, 0.1 Steel Plate Rubbing Zinc: Oxidization Non-Metal Asbestos 0.95 Asphalt 0.95 Basalt Carbon: Non-Oxidization, Graphite, 0.8-0.9, 0.7-0.8, 0.9 Silicone Carbide Ceramics 0.95 Clay 0.95 Concrete 0.95 Cloth Glass: Convex, Smooth, 0.76-0.8, 0.92-0.94, Lead-Boron 0.78-0.82 Plates 0.96...
-
Page 20: Accessories And Replacement Parts
Accessories and Replacement Parts R8888 Deluxe Hard Carrying Case R1500 Lightweight Tripod SD-MINI(8GB) Micro SD Memory Card TP-01 Beaded Thermocouple Wire Probe R2920 Surface Thermocouple Probe R2930 Right Angle Thermocouple Surface Probe R2940 Air/Gas Thermocouple Probe R2950 Immersion Thermocouple Probe R2960 Needle Tip Thermocouple Probe Don't see your part listed here? For a complete list of all accessories and replacement parts visit your product page on www.reedinstruments.com. -
Page 21: Product Warranty
REED Instruments guarantees this instrument to be free of defects in material or workmanship for a period of one (1) year from date of shipment. During the warranty period, REED Instruments will repair or replace, at no charge, products or parts of a product that proves to be defective because of improper material or workmanship, under normal use and maintenance. -
Page 22: Product Support
Product Support If you have any questions on your product, please contact your authorized REED distributor or REED Instruments Customer Service by phone at 1-877-849-2127 or by email at info@reedinstruments.com. Please visit www.REEDINSTRUMENTS.com for the most up-to-date manuals, datasheets, product guides and software. - Page 23 TEST & MEASURE WITH CONFIDENCE CHECK OUT OUR LATEST PRODUCTS! www.REEDINSTRUMENTS.com REED-Direct.ca info@REED-Direct.ca 1.800.561.8187...
