Transport- Attach / Remove
For ease of transport the back frame can be separated from the seat base. The back frame attaches
to the seat base by inserting the housing pins on the seat frame into the brackets on the side of the
chair back frame (see below).
Housing pins on back frame.
Steps involved in attaching the back frame:
Step 1
Firstly lie the back on top of the base with the
top facing forward.
Step 3
Slide the brackets onto the housing pins and
gently apply pressure to the top of the back and
push down to ensure it is securely in place.
30
Back Frame
Housing bracket on side of seat frame.
Step 2
Lift the back and position the brackets over the
housing pins.
Step 4
Then lock the back into position - push down on
the swing tab (A) on the housing bracket until it
locks into position over the chrome button (B).
(Locking)
