Table C.18 Modbus Register Map (Continued)
Address
Field
(hex)
017B Ic Rms Current
017C Average
Rms Current
017D In Rms Current
017E Vab
Rms Voltage
017F Vbc
Rms Voltage
0180 Vca
Rms Voltage
0181 Average
Rms Voltage
0182 kW3P Power
0183 kW3P
Avg Power
0184 HP
0185 kVAR3P
Power
0186 kVA3P Power
0187 Power Factor
0188 Ig Current
0189 3I2 Current
018A Vg Voltage
018B 3V2 Voltage
018C System
Frequency
018D % Unbalance
018E Reserved
018F Reserved
Date Code 20010719
Sample Low
0
0
0
0 if no 0
voltage option
0 if no 0
voltage option
0 if no 0
voltage option
0 if no 0
voltage option
–32768
0 if no
voltage option
0 if no voltage –32768
or single volt
–32768
0 if no
voltage option
0 if no –32768
voltage option
–32768
0 if no
voltage option
0 if no –100
voltage option
0
0
0
0 if no voltage
opt or delta
0 if no 0
voltage option
2000
0
®
Modbus RTU Communications Protocol
Modbus Register Map
High Step
65535 1
65535 1
65535 1
65535 1
65535 1
65535 1
65535 1
32767 1
32767 1
32767 1
32767 1
32767 1
100 1
65535 1
65535 1
65535 1
65535 1
7000 1
1000 1
