DICHIARAZIONE DI CONFORMITA' - DECLARATION OF CONFORMITY
DECLARATION DE CONFORMITE' - KONFORMITÄTS ERKLÄRUNG
Noi - The following - Nous soussignés - Der Unterzeichner :
dichiariamo sotto la nostra esclusiva responsabilità che il prodotto
hereby declares under full responsability that the following product
attestons sous notre entière responsabilité que le produit suivant
erklärt unter eigener Verantwortung, dass unten aufgeführtes Produkt
LAVABICCHIERI – LAVE-VERRES - GLASSWASHING MACHINE - GLÄSERSPÜLMASCHINE
al quale questa dichiarazione si riferisce è conforme alle seguenti norme:
for which this declaration refers to the conformity of the following standards:
auquel se réfère cette déclaration, est conforme aux normes suivantes:
folgendem Standard entspricht:
-
EN 60335-1 (1994) + A11,A1,A12,A13,A14,A15
Sicurezza degli apparecchi elettrici d'uso domestico e similare. Norme generali
Safety of household and similar electrical appliances-General requirements.
-
EN 60335-2-58 (1997)
Sicurezza degli apparecchi elettrici d'uso domestico e similare. Parte 2':Norme particolari lavastoviglie uso
collettivo.
Safety of household and similar electrical appliances-Part 2':Particular requirements for commercial electric
dishwashing machines.
-
EN 292-2 (1992) Part 1' - PART 2'
Sicurezza del macchinario-Concetti fondamentali-Principi generali progettazione-Specifiche e principi tecnici.
Safety of machinery-Basic concepts-General principles for design-Tecnical principles an specification
-
EN 61770- (2000)
Apparecchi elettrici connessi alla rete idrica. Disposizioni per evitare il ritorno d'acqua per effetto sifone e il
guasto dei complessi di raccordo
Electric appliances connected to the water mains. Avoidance of backsiphonage and failure of hose-sets
in base a quanto previsto dalle Direttive:
selon ce qui est prévu par les Directives:
on the basis of what is foreseen by the Directives:
aufgrund der vorgesehenen Richtilinien:
73/23/CEE, 89/392/CEE, 91/368CEE,92/31CEE, 93/44CEE, 93/68CEE
Decliniamo ogni responsabilità per sinistri a persone o a cose derivanti da manomissioni da parte di terzi o da carenze di manutenzione o riparazione.
Nous déclinons toute responsabilité pour sinistres à personnes ou à objets qui derivent de l'intervention de la part de tiers non specialistes ou de
carences de manutention ou reparation.
We decline any responsability for injuries or damage derived from machine misuse, abuse by others or improper machine maintenance or repairs.
Wir Iehnen jegliche Verantwortung für Schäden an Personen oder Dingen ab, die auf fehlerhaftes Eingreifen Dritter oder auf mängelhafte Wartung oder
Reparation zurückzuführen.
li
01/01/06
(data/date/Datum)
S400-ek / S460-ek / S480-ek
mod.

Advertisement

loading
Need help?

Need help?

Do you have a question about the S400-ek and is the answer not in the manual?

Questions and answers

Summary of Contents for lamber S400-ek

  • Page 1 Verantwortung, dass unten aufgeführtes Produkt LAVABICCHIERI – LAVE-VERRES - GLASSWASHING MACHINE - GLÄSERSPÜLMASCHINE S400-ek / S460-ek / S480-ek mod. al quale questa dichiarazione si riferisce è conforme alle seguenti norme: for which this declaration refers to the conformity of the following standards: auquel se réfère cette déclaration, est conforme aux normes suivantes:...
  • Page 2 - EMC - Noi - Nous soussignés - The following - Der Unterzeichner : LAMBER snc di Affaba F. e c. Via Italia 6 26855 Lodivecchio (LO) ITALY dichiariamo sotto la nostra esclusiva responsabilità che il prodotto attestons sous notre entière responsabilité que le produit suivant hereby declares under full responsability that the following product erklärt unter eigener Verantwortung, dass unten aufgeführtes Produkt...
  • Page 3 INDICE ITALIANO Note generali pag 05 Introduzione e norme di sicurezza pag. 06 Fate conoscenza con l'apparecchio pag. 10 Parte prima - NORME PER L'UTILIZZATORE pag. 11 Pannello Comandi pag. 12 Funzionamento ed uso, detersivi, manutenzione, inconvenienti possibili pag. 13 Parte seconda - NORME PER L'INSTALLATORE pag.
  • Page 4 NOTE GENERALI ITALIANO Vi ringraziamo per la scelta da Voi fatta nell'acquisto della Vostra LAVABICCHIERI. Il perfetto funzionamento della macchina e risultati di lavaggio ottimali sotto il profilo igienico-sanitario potranno essere garantiti solo se tutte le avvertenze del presente Manuale verranno rispettate. Ci auguriamo che le informazioni contenute nel presente manuale Vi siano di aiuto.
  • Page 5 INTRODUCTION ENGLISH AND SAFETY NORMS INTRODUCTION The machine is an industrial glass-washing machine. The machine is in conformity to the European Norms 89/336/CEE for the radio noises. According to EEC directive no. 23 of 19/02/1973 and the law of actuation no.791 of 18/10/1987, our appliances are built-up according to the good technique notes in force in Italy and abroad.
  • Page 6 Châssis, cuve et capot en acier inoxydable Elettrovalvola Entrata acqua Body,tank and Top in Stainless steel construction Electrovanne Entrée d 'eau Gehäuserahmen und Verblendungen aus CNS Water inlet solenoid valve Elektrisches Wassereinlaufventil Dosatore additivo di risciacquo Doseur de produit pour rinçage Rinse aid dispenser Nachspülmitteldosiergerät descr-s400-ek-elettronica-2006...
  • Page 7 NORME PER L'UTENTE INSTRUCTIONS POUR L'UTILISATEUR INSTRUCTIONS FOR THE USER BEDIENUNGSANLEITUNG...
  • Page 8 PANNELLO COMANDI EMPLOI CONTROLES CONTROL PANEL STEUERTAFEL Interruttore generale Interrupteur général Main switch Hauptschalter Pulsante selezione tempo lavaggio Bouton sélecteur temps de lavage Wash time selection pushbutton Programmwahlschalter Pulsante ciclo Bouton cycle Cycle pushbutton Programmdrucktaste Lampada ciclo Lampe indicatrice de cycle Cycle lamp Programmkontrollampe Lampada temperatura...
  • Page 9 ENGLISH First Section - FOR THE USER WORKING AND USE The glasswashing machine can wash up to 900 mixed-size glasses every hour. The machine protection degree is IP21, therefore it should not be washed with direct high pressure jet water. The objects to be washed should be correctly arranged for a good washing-up result.
  • Page 10 To continue carry a new basket, introduce it in This operation must be done when lamp “E” the machine, close the door and press button is flashing with door open and door closed . “C”. Lift the overflow out of the tank and close the door .
  • Page 11 DAILY MAINTENANCE CLEANING PREVENTIVE MAINTENANCE Disconnect the machine with pushbutton "A"; PRECAUTION CLEANING Lift the overflow pipe and let the water INSTRUCTIONS drain out of the tank; Wash thoroughly the tank and the filter housings to remove all impurities; IMPORTANT: Before carrying out the Take the filters out and clean them under cleaning maintenance...
  • Page 12 CLEANSING AGENTS The choice of a suitable cleansing agent is an essential condition if you want to obtain extremely good washing results as regards hygienic results. That’s why it’s important to consider some points. First of all only highly alkaline and chlorine-active antifoam products, especially made for industrial dish-washing machines, must be used and they must be produced by well-known reliable Firms.
  • Page 13 NORME PER L’INSTALLATORE Le istruzioni che seguono sono rivolte a personale qualificato, il solo autorizzato ad attuare le verifiche e le eventuali riparazioni. La Ditta declina ogni responsabilità nel caso di interventi effettuati da personale non qualificato e/o utilizzo di ricambi non originali. INSTRUCTIONS POUR L'INSTALLATEUR Les instructions suivantes sont adressées à...
  • Page 14 INSTALLATION SCHEMA ALLACCIAMENTI INSTALLATIONSBLATT INSTALLATION S400-ek/S460-ek/S480-ek S400-ek=275 S460-ek=295 S480-ek=325 Altezza massima per scarico a muro - Hauteur maximale pour vidange à mur Maximum height for drain to wall - Maximale Bodenhöhe für Wandwasserablauf Entrata acqua - Chargement eau 3/4" G Water inlet - Wasseranschluß...
  • Page 15 ENGLISH Second Section - FOR THE INSTALLER During installation carry out a good machine levelling, which is a prerequisite for a correct operation thereof. The Manufacturer cannot assume any responsability for any damage to persons or property deriving from the non-observance of the above specified norms. For a correct installation see the drawing on page 30.
  • Page 16: Water Connections

    WATER CONNECTIONS WORK TEMPERATURES Carefully comply with any national or Washing temperature 55° 60°C ÷ regional regulations in force. Rinse temperature 80° 85°C ÷ Water installation must have the following characteristics: n.b.: To help a correct working of the thermocontrol system, do NOT adjust the thermostat during the washing cycle.
  • Page 17: Connections Scheme

    Portata pompa dosatrice Portée pompe doseur de lavage - To increase the detergent Detergent pump delivery dose turn CW the regulation Wassermenge screw . 1 cc/sec=3,6 Lit/h - Um die Reinigungsmittelsmenge zu erhöhen, drehen Sie den Schraubenzieher im Uhrzeigersinn. Colle-s400-EK-2005...
  • Page 18 SCHEMA ELECTRIQUE SCHEMA ELETTRICO SCHALTSCHEMA WIRING DIAGRAM con dosatore di lavaggio avec doseur de produit lessiviel with detergent pump 230 V 50Hz mit Waschspülmitteldosiergerät Fa15 Fa10 Fa11 P .S. Interruttore generale Interrupteur général Mai n switch Hauptschalter Finecorsa Mi c rointerrupteur Limit switch Endschalter Resistenza boiler...
  • Page 19 SCHEDA ELETTRONICA FICHE ELECTRONIQUE P .C.BOARD ELEKTRONISCHE STEURUNG filo/fil/wire/draht ITA SCARICO VIDANGE DRAIN PUMP ABLAUFPUMPE RIGENERA REGENERATION REGENERATIN ENTKALKUNG LAVAGGIO LAVAGE WASHING WASCHUNG RISCIACQUO RINÇAGE RINSING SPÜLUNG FASE PHASE' PHASE PHASE NEUTRO NEUTRE NEUTRAL UNGELADEN LIVELLO PRESSOSTATO NIVEAU PRESSOSTAT PRESSOSTAT LEVEL DRUCKWÄCHTER TEMPERATURA (TERMOSTATO) TEMPERATURE /THERMOSTAT)
