Real-Time Processing Options

Chapter 2
Real-Time Processing Options
The U5310A ADC Card provides several optional modes. This section describes each acquisition
mode and associated real-time signal processing.

2.1 Easy firmware switch

2.2 Digitizer firmware (DGT option)
2.3 Real-time averaging (AVG option)
The modes available with your product depends on the firmware options ordered with your products.
To check which options and mode are present on your ADC card you can use the MD3 Software
Front Panel from the: Windows Start Menu > Acqiris > MD3 > Acqiris MD3 SFP. Then use the
menu Help > About. The field System Options gives the option list.
2.1 Easy firmware switch
A simple call to the configuration function will enable to switch to the required option.
16
16
17
20
