Approvals
Approvals
(valid for marked equipment)
Construction Product
PY X-M-05 + PY X-M-10: VdS 0786-CPD-xxxx
Directive
(89/106/EWG)
(in preparation)
VdS
PY X-M-05 + PY X-M-10:
in preparation
PY X-M-xx + PY X-MA-xx
Rated Voltage
115V AC
UL, cUL
230V AC
in preparation
24V AC/ DC
PYRA Xenon beacons PY X-M(A)-xx comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
Taking into Operation
Safety notes:
- Installation must be carried out by an electrician in compliance with the latest codes and regulations.
- Danger: High voltage may be present.
- Prior to opening, it must be ensured that no voltage is applied to the device.
- Before electrical connection, the supply voltage on the type plate is to be checked. The wrong operating voltage can lead to
damages or to the destruction of the equipment.
- During installation it must be ensured that the connection cables are secured against tension and distortion.
Please observe: The devices are not designed for portable use.
- CAUTION: When making installation, route field wiring away from sharp projections, corners and internal components.
- The function of the unit is only guaranteed if the upper and lower section is joined correctly.
- In order to prevent detriment to sight, continuously looking directly in the activated light is to be avoided.
Opening the housing
1. 2.
3/8
The unit is not closed when delivered. Sealing plugs for the housing screws are available as accessories.
Electrical connection:
7 [0.28"]
stranded
solid
Connecting cables
S1,
Tone Selector Switch
Volume
Control
PY X-MA-xx
Operation voltage for
The beacons satisfy the requirements of the standard EN54-23 (Synchronization).
Caution: In order to ensure synchronization, the devices must be operated with the same potential..
085 501 972
Rated voltage
Operating voltage range acc. to EN54-23
Lens colours
Signalling area
Environmental
protection class
Installation position
Testing takes place using the supplied diaphragm nipple and the outer fastening bores.
G212xxx, data see Construction Product Directive (89/106/EWG)
Visual Signal Appliance - General Signaling Equipment - UEES, UEES7
Suitable for indoor and outdoor use.
Warning: Not to be used as a Visual Public Mode Alarm Notification Appliance.
According to CSA-C22.2 No. 205-M1983 clause 4.3.4 the connection is limited to max. three
leads.
By loosing the four
cover screws, the upper
section can be
removed.
7 [0.28"]
Operation voltage
for beacon
sounder
12V DC
EN 54-23 Category O: see document 30360-005-1
see document 30360-005-1
Closing the housing
1.
3/8
PY X-M-xx
Connection for
operation voltage
30360-004
24V DC
10V – 60V DC
red, clear
Type B
2.
The housing is closed by
turning the cover screws to
the limit position until the
housing locks into place.
48V DC
5
